VCF 9 Management Services Lab Downsize

apiVersion: apps/v1
kind: StatefulSet
metadata:
  annotations:
    meta.helm.sh/release-name: vcf-ops-logs
    meta.helm.sh/release-namespace: ops-logs
  creationTimestamp: "2026-05-12T16:04:45Z"
  generation: 1
  labels:
    app.kubernetes.io/instance: vcf-ops-logs
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: vcf-ops-logs
    app.kubernetes.io/version: 0.0.1574
    helm.sh/chart: vcf-ops-logs-0.0.1574
    helm.toolkit.fluxcd.io/name: vcf-ops-logs
    helm.toolkit.fluxcd.io/namespace: ops-logs
    monitoring: vcf-ops-logs-app
    ops.vmsp.vmware.com/type: log-processor-service
  name: log-processor
  namespace: ops-logs
  resourceVersion: "13212589"
  uid: 0e479d18-21a5-4753-92e6-c868482dfdc8
spec:
  persistentVolumeClaimRetentionPolicy:
    whenDeleted: Retain
    whenScaled: Retain
  podManagementPolicy: Parallel
  replicas: 1
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      app.kubernetes.io/instance: vcf-ops-logs
      app.kubernetes.io/name: vcf-ops-logs
  serviceName: log-processor-svc
  template:
    metadata:
      annotations:
        identity.vmsp.vmware.com/serviceaccount: opslogs-client
      labels:
        app.kubernetes.io/instance: vcf-ops-logs
        app.kubernetes.io/name: vcf-ops-logs
        monitoring: vcf-ops-logs-app
        ops.vmsp.vmware.com/type: log-processor-resource
    spec:
      affinity:
        podAntiAffinity:
          preferredDuringSchedulingIgnoredDuringExecution:
          - podAffinityTerm:
              labelSelector:
                matchLabels:
                  app.kubernetes.io/instance: vcf-ops-logs
                  app.kubernetes.io/name: vcf-ops-logs
              topologyKey: kubernetes.io/hostname
            weight: 100
      containers:
      - envFrom:
        - configMapRef:
            name: ops-logs-config
        image: registry.vmsp-platform.svc.cluster.local:5000/images/ops-logs/9.1.0.0.25346055/ops-logs/vcf-ops-logs:0.0.1574
        imagePullPolicy: IfNotPresent
        livenessProbe:
          failureThreshold: 15
          httpGet:
            path: /healthz
            port: web-nonssl
            scheme: HTTP
          initialDelaySeconds: 45
          periodSeconds: 5
          successThreshold: 1
          timeoutSeconds: 1
        name: vcf-ops-logs
        ports:
        - containerPort: 9000
          name: cfapi-nonssl
          protocol: TCP
        - containerPort: 514
          name: syslog-nonssl
          protocol: TCP
        - containerPort: 9543
          name: cfapi-ssl
          protocol: TCP
        - containerPort: 1514
          name: syslog-ssl
          protocol: TCP
        - containerPort: 8080
          name: web-nonssl
          protocol: TCP
        readinessProbe:
          failureThreshold: 15
          httpGet:
            path: /readyz
            port: web-nonssl
            scheme: HTTP
          initialDelaySeconds: 45
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 5
        resources:
          limits:
            ephemeral-storage: 2Gi
            memory: 6Gi
          requests:
            cpu: "3"
            ephemeral-storage: 2Gi
            memory: 6Gi
        securityContext:
          capabilities:
            drop:
            - CAP_CHOWN
            - CAP_DAC_OVERRIDE
            - CAP_FOWNER
            - CAP_NET_RAW
            - CAP_MKNOD
        startupProbe:
          failureThreshold: 60
          httpGet:
            path: /healthz
            port: web-nonssl
            scheme: HTTP
          initialDelaySeconds: 45
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /opt/vmware/ops-logs/data
          name: opslogs-data
        - mountPath: /opt/vmware/ops-logs/debug
          name: opslogs-debug
        - mountPath: /opt/vmware/certs/opensearch
          name: opensearch-certs
        - mountPath: /opt/vmware/certs/ops-logs
          name: opslogs-certs
        - mountPath: /opt/vmware/certs/ingress
          name: ingress-certs
        - mountPath: /opt/vmware/certs/auth
          name: opslogs-auth
        - mountPath: /opt/vmware/secrets
          name: logs-secrets
          readOnly: true
        - mountPath: /opt/vmware/security/platform-trust
          name: vmsp-certs
          readOnly: true
      - image: registry.vmsp-platform.svc.cluster.local:5000/images/ops-logs/9.1.0.0.25346055/ops-logs/vcf-ops-logs-ui:0.0.1574
        imagePullPolicy: IfNotPresent
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /nginx-health
            port: http-ui
            scheme: HTTP
          initialDelaySeconds: 10
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 5
        name: ui-server
        ports:
        - containerPort: 8081
          name: http-ui
          protocol: TCP
        - containerPort: 8444
          name: https-ui
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /nginx-health
            port: http-ui
            scheme: HTTP
          initialDelaySeconds: 10
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 5
        resources:
          limits:
            cpu: 200m
            memory: 256Mi
          requests:
            cpu: 100m
            memory: 128Mi
        securityContext:
          capabilities:
            drop:
            - CAP_CHOWN
            - CAP_DAC_OVERRIDE
            - CAP_FOWNER
            - CAP_NET_RAW
            - CAP_MKNOD
          runAsNonRoot: true
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /etc/nginx/conf.d
          name: ui-nginx-config
          readOnly: true
        - mountPath: /etc/nginx/certs
          name: ui-certs
          readOnly: true
      dnsPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext:
        fsGroup: 3000
        runAsGroup: 3000
        runAsUser: 2000
      serviceAccount: log-processor
      serviceAccountName: log-processor
      terminationGracePeriodSeconds: 240
      volumes:
      - name: opensearch-certs
        secret:
          defaultMode: 384
          secretName: tls-for-opensearch-key-pair
      - name: opensearch-admin-certs
        secret:
          defaultMode: 384
          secretName: tls-for-opensearch-admin-key-pair
      - name: opslogs-certs
        secret:
          defaultMode: 384
          secretName: tls-for-opslogs-key-pair
      - name: ingress-certs
        secret:
          defaultMode: 384
          secretName: ingress-service-cert
      - name: opslogs-auth
        secret:
          defaultMode: 384
          secretName: auth-keypair-secret
      - name: logs-secrets
        secret:
          defaultMode: 384
          secretName: ops-logs-secrets
      - configMap:
          defaultMode: 384
          items:
          - key: bundle.pem
            path: bundle.pem
          name: platform-trust
        name: vmsp-certs
      - configMap:
          defaultMode: 384
          name: log-processor-ui-nginx-config
        name: ui-nginx-config
      - name: ui-certs
        secret:
          defaultMode: 384
          secretName: tls-for-opslogs-key-pair
  updateStrategy:
    rollingUpdate:
      partition: 0
    type: RollingUpdate
  volumeClaimTemplates:
  - apiVersion: v1
    kind: PersistentVolumeClaim
    metadata:
      labels:
        velero.io/exclude-from-backup: "true"
        volume-groups.vmsp.vmware.com/resizable: "false"
      name: opslogs-debug
    spec:
      accessModes:
      - ReadWriteOnce
      resources:
        requests:
          storage: 15Gi
      volumeMode: Filesystem
    status:
      phase: Pending
  - apiVersion: v1
    kind: PersistentVolumeClaim
    metadata:
      labels:
        velero.io/exclude-from-backup: "true"
        volume-groups.vmsp.vmware.com/resizable: "false"
      name: opslogs-data
    spec:
      accessModes:
      - ReadWriteOnce
      resources:
        requests:
          storage: 60Gi
      volumeMode: Filesystem
    status:
      phase: Pending
status:
  availableReplicas: 1
  collisionCount: 0
  currentReplicas: 1
  currentRevision: log-processor-774bcc4967
  observedGeneration: 1
  readyReplicas: 1
  replicas: 1
  updateRevision: log-processor-774bcc4967
  updatedReplicas: 1

apiVersion: apps/v1
kind: StatefulSet
metadata:
  annotations:
    majorVersion: "3"
    meta.helm.sh/release-name: vcf-ops-logs
    meta.helm.sh/release-namespace: ops-logs
  creationTimestamp: "2026-05-12T16:04:45Z"
  generation: 2
  labels:
    app.kubernetes.io/component: log-store
    app.kubernetes.io/instance: vcf-ops-logs
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: opensearch
    app.kubernetes.io/version: 3.0.0
    helm.sh/chart: opensearch-3.0.0
    helm.toolkit.fluxcd.io/name: vcf-ops-logs
    helm.toolkit.fluxcd.io/namespace: ops-logs
    ops.vmsp.vmware.com/type: log-store-service
  name: log-store
  namespace: ops-logs
  resourceVersion: "13211289"
  uid: 5859f867-be7b-42cc-9cf1-0a33fa15c58d
spec:
  persistentVolumeClaimRetentionPolicy:
    whenDeleted: Retain
    whenScaled: Retain
  podManagementPolicy: Parallel
  replicas: 1
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      app.kubernetes.io/instance: vcf-ops-logs
      app.kubernetes.io/name: opensearch
  serviceName: log-store-headless
  template:
    metadata:
      annotations:
        configchecksum: 88acb1d6fcb84e84077a20e3544fdf5c07fee8c04a7fcd3e5d35d28f6d76294
      labels:
        app.kubernetes.io/component: log-store
        app.kubernetes.io/instance: vcf-ops-logs
        app.kubernetes.io/managed-by: Helm
        app.kubernetes.io/name: opensearch
        app.kubernetes.io/version: 3.0.0
        helm.sh/chart: opensearch-3.0.0
        ops.vmsp.vmware.com/type: log-store-resource
      name: log-store
    spec:
      affinity:
        podAntiAffinity:
          preferredDuringSchedulingIgnoredDuringExecution:
          - podAffinityTerm:
              labelSelector:
                matchExpressions:
                - key: app.kubernetes.io/instance
                  operator: In
                  values:
                  - vcf-ops-logs
                - key: app.kubernetes.io/name
                  operator: In
                  values:
                  - opensearch
              topologyKey: kubernetes.io/hostname
            weight: 1
      automountServiceAccountToken: false
      containers:
      - env:
        - name: node.name
          valueFrom:
            fieldRef:
              apiVersion: v1
              fieldPath: metadata.name
        - name: cluster.initial_master_nodes
          value: log-store-0,
        - name: discovery.seed_hosts
          value: log-store-headless
        - name: cluster.name
          value: log-store
        - name: network.host
          value: 0.0.0.0
        - name: OPENSEARCH_JAVA_OPTS
          value: -Xms5120m -Xmx5120m -Djavax.net.ssl.trustStore=/usr/share/opensearch/config/truststore/bundle.jks
            -Djavax.net.ssl.trustStorePassword=changeit -Djava.util.logging.config.file=/usr/share/opensearch/config/bc.logging.properties
        - name: node.roles
          value: master,ingest,data,remote_cluster_client,warm,
        - name: DISABLE_INSTALL_DEMO_CONFIG
          value: "true"
        - name: LOG_PROCESSOR_USER
          value: log-processor-user
        - name: LOG_PROCESSOR_ROLE
          value: log-processor-role
        - name: KEYSTORE_UTIL_SECRET
          valueFrom:
            configMapKeyRef:
              key: LOGS_OPENSEARCH_KEYSTORE_UTIL
              name: ops-logs-config
        - name: CLIENT_NAME
          valueFrom:
            configMapKeyRef:
              key: CLIENT_NAME
              name: ops-logs-config
        image: registry.vmsp-platform.svc.cluster.local:5000/images/ops-logs/9.1.0.0.25346055/ops-logs/opensearchproject/log-store:3.0.0-fips-1.8
        imagePullPolicy: IfNotPresent
        name: opensearch
        ports:
        - containerPort: 9200
          name: http
          protocol: TCP
        - containerPort: 9300
          name: transport
          protocol: TCP
        - containerPort: 9600
          name: metrics
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          periodSeconds: 5
          successThreshold: 1
          tcpSocket:
            port: 9200
          timeoutSeconds: 3
        resources:
          limits:
            cpu: "5"
            ephemeral-storage: 2Gi
            memory: 10Gi
          requests:
            cpu: "5"
            ephemeral-storage: 2Gi
            memory: 10Gi
        securityContext:
          capabilities:
            drop:
            - ALL
          runAsNonRoot: true
          runAsUser: 1000
        startupProbe:
          failureThreshold: 30
          initialDelaySeconds: 5
          periodSeconds: 10
          successThreshold: 1
          tcpSocket:
            port: 9200
          timeoutSeconds: 3
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /usr/share/opensearch/data
          name: log-store
        - mountPath: /usr/share/opensearch/config/certs
          name: tls-for-opensearch-key-pair
        - mountPath: /usr/share/opensearch/config/certs/admin
          name: tls-for-opensearch-admin-key-pair
        - mountPath: /usr/share/opensearch/config/certs/log-processor
          name: tls-for-opslogs-key-pair
        - mountPath: /usr/share/opensearch/config/ops-logs-secrets
          name: ops-logs-secrets-mount
        - mountPath: /usr/share/opensearch/config/s3-secrets
          name: s3-secret-mount
        - mountPath: /usr/share/opensearch/config/s3-backup-restore-secrets
          name: s3-backup-restore-secret-mount
        - mountPath: /usr/share/opensearch/config/opensearch.yml
          name: config-emptydir
          subPath: opensearch.yml
        - mountPath: /usr/share/opensearch/cayman-opensearch-util.sh
          name: cayman-opensearch-util
          readOnly: true
          subPath: cayman-opensearch-util.sh
        - mountPath: /usr/share/opensearch/config/bc.logging.properties
          name: cayman-opensearch-bc-logging
          readOnly: true
          subPath: bc.logging.properties
        - mountPath: /usr/share/opensearch/config/truststore
          name: truststore-volume
          readOnly: true
      dnsPolicy: ClusterFirst
      enableServiceLinks: true
      initContainers:
      - args:
        - chown -R 1000:1000 /usr/share/opensearch/data
        command:
        - sh
        - -c
        image: registry.vmsp-platform.svc.cluster.local:5000/images/ops-logs/9.1.0.0.25346055/ops-logs/busybox:latest
        imagePullPolicy: IfNotPresent
        name: fsgroup-volume
        resources:
          limits:
            cpu: 100m
            memory: 128Mi
          requests:
            cpu: 100m
            memory: 128Mi
        securityContext:
          runAsUser: 0
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /usr/share/opensearch/data
          name: log-store
      - command:
        - sh
        - -c
        - |
          #!/usr/bin/env bash
          cp -r /tmp/configfolder/*  /tmp/config/
        image: registry.vmsp-platform.svc.cluster.local:5000/images/ops-logs/9.1.0.0.25346055/ops-logs/opensearchproject/log-store:3.0.0-fips-1.8
        imagePullPolicy: IfNotPresent
        name: configfile
        resources:
          limits:
            cpu: 100m
            memory: 128Mi
          requests:
            cpu: 100m
            memory: 128Mi
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /tmp/config/
          name: config-emptydir
        - mountPath: /tmp/configfolder/opensearch.yml
          name: config
          subPath: opensearch.yml
      priorityClassName: high
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext:
        fsGroup: 1000
        runAsUser: 1000
      serviceAccount: log-store-sa
      serviceAccountName: log-store-sa
      terminationGracePeriodSeconds: 240
      volumes:
      - configMap:
          defaultMode: 420
          name: log-store-config
        name: config
      - emptyDir: {}
        name: config-emptydir
      - name: tls-for-opensearch-key-pair
        secret:
          defaultMode: 384
          secretName: tls-for-opensearch-key-pair
      - name: tls-for-opensearch-admin-key-pair
        secret:
          defaultMode: 384
          secretName: tls-for-opensearch-admin-key-pair
      - name: tls-for-opslogs-key-pair
        secret:
          defaultMode: 384
          secretName: tls-for-opslogs-key-pair
      - name: ops-logs-secrets-mount
        secret:
          defaultMode: 384
          secretName: ops-logs-secrets
      - name: s3-secret-mount
        secret:
          defaultMode: 384
          secretName: s3-secret
      - name: s3-backup-restore-secret-mount
        secret:
          defaultMode: 384
          secretName: ops-logs-bucket-credentials
      - configMap:
          defaultMode: 384
          name: cayman-opensearch-util-script
        name: cayman-opensearch-util
      - configMap:
          defaultMode: 384
          name: cayman-opensearch-bc-logging
        name: cayman-opensearch-bc-logging
      - configMap:
          defaultMode: 384
          items:
          - key: bundle.jks
            path: bundle.jks
          name: platform-trust-no-default
        name: truststore-volume
  updateStrategy:
    type: RollingUpdate
  volumeClaimTemplates:
  - apiVersion: v1
    kind: PersistentVolumeClaim
    metadata:
      labels:
        app.kubernetes.io/component: log-store
        app.kubernetes.io/instance: vcf-ops-logs
        app.kubernetes.io/managed-by: Helm
        app.kubernetes.io/name: opensearch
        app.kubernetes.io/version: 3.0.0
        helm.sh/chart: opensearch-3.0.0
        vcf.vmware.com/keep-during-restore: "true"
        velero.io/exclude-from-backup: "true"
      name: log-store
    spec:
      accessModes:
      - ReadWriteOnce
      resources:
        requests:
          storage: 500Gi
      volumeMode: Filesystem
    status:
      phase: Pending
status:
  availableReplicas: 1
  collisionCount: 0
  currentReplicas: 1
  currentRevision: log-store-95968949d
  observedGeneration: 2
  readyReplicas: 1
  replicas: 1
  updateRevision: log-store-95968949d
  updatedReplicas: 1

apiVersion: gateway.envoyproxy.io/v1alpha1
kind: EnvoyProxy
metadata:
  annotations:
    meta.helm.sh/release-name: ops-logs-gateway
    meta.helm.sh/release-namespace: vmsp-platform
  creationTimestamp: "2026-05-12T16:04:50Z"
  generation: 1
  labels:
    app.kubernetes.io/managed-by: Helm
    helm.toolkit.fluxcd.io/name: ops-logs-gateway
    helm.toolkit.fluxcd.io/namespace: vmsp-platform
  name: ops-logs-gateway-config
  namespace: vmsp-platform
  resourceVersion: "176946"
  uid: 1f3c50f1-4e24-4b87-9578-076a35b941a8
spec:
  logging:
    level:
      default: warn
  provider:
    kubernetes:
      envoyDeployment:
        container:
          volumeMounts:
          - mountPath: /tmp
            name: shutdown-manager
        name: ops-logs-gateway
        patch:
          type: StrategicMerge
          value:
            metadata:
              labels:
                ops.vmsp.vmware.com/type: envoygatewayproxy-service
            spec:
              template:
                metadata:
                  labels:
                    ops.vmsp.vmware.com/type: envoygatewayproxy-service
                spec:
                  affinity:
                    podAntiAffinity:
                      preferredDuringSchedulingIgnoredDuringExecution:
                      - podAffinityTerm:
                          labelSelector:
                            matchLabels:
                              gateway.envoyproxy.io/owning-gateway-name: ops-logs-gateway
                          topologyKey: kubernetes.io/hostname
                        weight: 100
                  containers:
                  - image: registry.vmsp-platform.svc.cluster.local:5000/images/envoy:v1.34.1
                    name: envoy
                    resources:
                      limits:
                        memory: 2Gi
                      requests:
                        cpu: 4000m
                        memory: 2Gi
                    volumeMounts:
                    - mountPath: /etc/ssl/certs
                      name: config-volume
                  - image: registry.vmsp-platform.svc.cluster.local:5000/images/envoyproxy-gateway:v1.5.0
                    name: shutdown-manager
                    resources:
                      limits:
                        cpu: 50m
                        memory: 256Mi
                      requests:
                        cpu: 5m
                        memory: 32Mi
                    volumeMounts:
                    - mountPath: /tmp
                      name: shutdown-manager
                  priorityClassName: vmsp-high
        pod:
          volumes:
          - emptyDir:
              medium: Memory
            name: shutdown-manager
          - configMap:
              items:
              - key: bundle.pem
                path: ca-certificates.crt
              name: platform-trust
            name: config-volume
        replicas: 1
      envoyService:
        allocateLoadBalancerNodePorts: false
        externalTrafficPolicy: Local
        loadBalancerClass: envoy
        name: ops-logs-gateway
        type: LoadBalancer
    type: Kubernetes
  telemetry:
    accessLog:
      disable: true

apiVersion: acid.zalan.do/v1
kind: postgresql
metadata:
  annotations:
    vmsp.vmware.com/delete-protection: "true"
  creationTimestamp: "2026-05-12T13:50:10Z"
  generation: 2
  labels:
    ops.vmsp.vmware.com/type: pgdatabase
    velero.io/exclude-from-backup: "true"
  name: vcf-fleet-lcm-db
  namespace: vcf-fleet-lcm
  resourceVersion: "13213812"
  uid: b1cae9df-2a4d-4ddd-9f42-e5846ca2565a
spec:
  additionalVolumes:
  - mountPath: /usr/local/share/ca-certificates/client/
    name: seaweedfs-client-cert
    targetContainers:
    - postgres
    - walg
    volumeSource:
      secret:
        optional: false
        secretName: seaweedfs-client-cert
  - mountPath: /usr/local/share/ca-certificates/tls/
    name: pgbackup-sidecar-tls-cert
    targetContainers:
    - walg
    volumeSource:
      secret:
        optional: false
        secretName: vcf-fleet-lcm-db-postgres-cert-secret
  allowedSourceRanges: null
  enableConnectionPooler: false
  enableReplicaConnectionPooler: false
  env:
  - name: AWS_ACCESS_KEY_ID
    valueFrom:
      secretKeyRef:
        key: access_key
        name: vcf-fleet-lcm.db.vcf-fleet-lcm-db.wal-backup-credentials
  - name: AWS_SECRET_ACCESS_KEY
    valueFrom:
      secretKeyRef:
        key: secret_key
        name: vcf-fleet-lcm.db.vcf-fleet-lcm-db.wal-backup-credentials
  - name: AWS_ENDPOINT
    value: https://seaweedfs-s3.vmsp-platform.svc.cluster.local:8443
  - name: WALG_S3_CA_CERT_FILE
    value: /usr/local/share/ca-certificates/client/ca.crt
  - name: USE_WALG_BACKUP
    value: "true"
  - name: USE_WALG_RESTORE
    value: "true"
  - name: CLONE_USE_WALG_RESTORE
    value: "true"
  - name: CLONE_WAL_BUCKET_SCOPE_PREFIX
  - name: BACKUP_NUM_TO_RETAIN
    value: "1"
  - name: WAL_S3_BUCKET
    value: vcf-fleet-lcm.db.vcf-fleet-lcm-db.wal-backup
  - name: AWS_S3_FORCE_PATH_STYLE
    value: "true"
  - name: BACKUP_SCHEDULE
    value: '#0 25 31 2 * '
  nodeAffinity:
    preferredDuringSchedulingIgnoredDuringExecution:
    - preference:
        matchExpressions:
        - key: node.kubernetes.io/instance-type
          operator: In
          values:
          - vsphere-vm.cpu-12.mem-24gb.os-photon
      weight: 1
  numberOfInstances: 3
  patroni:
    failsafe_mode: true
    retry_timeout: 20
    synchronous_mode: true
    synchronous_mode_strict: true
    synchronous_node_count: 1
    ttl: 50
  postgresql:
    parameters:
      archive_cleanup_command: curl -sf --connect-timeout 1 --max-time 5 http://127.0.0.1:8008/replica
        > /dev/null && envdir "/run/etc/wal-e.d/env" pg_archivecleanup "/home/postgres/pgdata/pgroot/data/pg_wal"
        "%r" || exit 0
      archive_command: (curl -sf --connect-timeout 1 --max-time 5 http://127.0.0.1:8008/primary
        > /dev/null || exit 0) && envdir "/run/etc/wal-e.d/env" wal-g wal-push "%p"
      archive_timeout: 900s
      client_min_messages: error
      log_destination: stderr
      log_line_prefix: '%m %c %x %d %u %r %p %l'
      log_parameter_max_length: "0"
      log_parameter_max_length_on_error: "0"
      logging_collector: "off"
      max_connections: "500"
      password_encryption: scram-sha-256
      pgaudit.log: none
      pgaudit.log_catalog: "off"
      pgaudit.log_parameter: "off"
      restore_command: 'envdir "/run/etc/wal-e.d/env" /bin/bash -c "echo $(date -u
        +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: start %f >&2; if ! timeout 1s bash -c ''exec
        3<>/dev/tcp/seaweedfs-s3.vmsp-platform.svc.cluster.local/8443''; then echo
        $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: preflight-fail https://seaweedfs-s3.vmsp-platform.svc.cluster.local:8443
        >&2; exit 1; fi; if timeout 30s /scripts/restore_command.sh \"%f\" \"%p\";
        then if [ -s \"%p\" ]; then echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc:
        success %f >&2; exit 0; else echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC)
        rc: empty-file %f >&2; exit 1; fi; else rc=$?; if [ \"${rc:-0}\" -eq 124 ];
        then echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: fetch-timeout %f >&2;
        else echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: fetch-fail %f rc=${rc:-?}
        >&2; fi; exit 1; fi"'
      shared_preload_libraries: bg_mon,pg_stat_statements,pgextwlist,pg_auth_mon,set_user,timescaledb,pg_cron,pg_stat_kcache
      statement_timeout: "30000"
      synchronous_commit: "on"
    version: "16"
  preparedDatabases:
    vcffleetlcmdb:
      defaultUsers: true
      schemas:
        public: {}
  resources:
    limits:
      cpu: "1"
      memory: 3048Mi
    requests:
      cpu: 500m
      memory: 512Mi
  sidecars:
  - env:
    - name: DATA_SOURCE_URI
      value: localhost:5432/postgres?sslmode=disable
    - name: DATA_SOURCE_USER
      value: $(POSTGRES_USER)
    - name: DATA_SOURCE_PASS
      value: $(POSTGRES_PASSWORD)
    image: registry.vmsp-platform.svc.cluster.local:5000/images/prometheuscommunity-postgres-exporter:v0.18.1
    name: metrics-exporter
    ports:
    - containerPort: 9187
      name: http-metrics
      protocol: TCP
  - env:
    - name: PGPORT
      value: "5432"
    - name: PGHOST
      value: vcf-fleet-lcm-db.vcf-fleet-lcm.svc.cluster.local
    - name: WALE_S3_PREFIX
      value: s3://vcf-fleet-lcm.db.vcf-fleet-lcm-db.wal-backup/spilo/vcf-fleet-lcm-vcf-fleet-lcm-db/wal/16/
    - name: AWS_ACCESS_KEY_ID
      valueFrom:
        secretKeyRef:
          key: access_key
          name: vcf-fleet-lcm.db.vcf-fleet-lcm-db.wal-backup-credentials
    - name: AWS_SECRET_ACCESS_KEY
      valueFrom:
        secretKeyRef:
          key: secret_key
          name: vcf-fleet-lcm.db.vcf-fleet-lcm-db.wal-backup-credentials
    - name: AWS_ENDPOINT
      value: https://seaweedfs-s3.vmsp-platform.svc.cluster.local:8443
    - name: WALG_S3_CA_CERT_FILE
      value: /usr/local/share/ca-certificates/client/ca.crt
    - name: USE_WALG_BACKUP
      value: "true"
    - name: USE_WALG_RESTORE
      value: "true"
    - name: CLONE_USE_WALG_RESTORE
      value: "true"
    - name: CLONE_WAL_BUCKET_SCOPE_PREFIX
    - name: BACKUP_NUM_TO_RETAIN
      value: "1"
    - name: WAL_S3_BUCKET
      value: vcf-fleet-lcm.db.vcf-fleet-lcm-db.wal-backup
    - name: AWS_S3_FORCE_PATH_STYLE
      value: "true"
    - name: BACKUP_SCHEDULE
      value: '#0 25 31 2 * '
    image: registry.vmsp-platform.svc.cluster.local:5000/images/pgbackup:v1.0.0
    name: walg
    ports:
    - containerPort: 9100
      name: walg
      protocol: TCP
    resources:
      limits:
        cpu: 1000m
        memory: 768Mi
      requests:
        cpu: 100m
        memory: 100Mi
  teamId: vcf-fleet-lcm-db
  tls:
    caFile: ca.crt
    secretName: vcf-fleet-lcm-db-postgres-cert-secret
  users:
    postgres:
    - superuser
    - createdb
  volume:
    size: 30Gi
status:
  PostgresClusterStatus: Running

apiVersion: acid.zalan.do/v1
kind: postgresql
metadata:
  annotations:
    vmsp.vmware.com/delete-protection: "true"
  creationTimestamp: "2026-05-12T13:51:09Z"
  generation: 2
  labels:
    ops.vmsp.vmware.com/type: pgdatabase
    velero.io/exclude-from-backup: "true"
  name: vcf-sddc-lcm-db
  namespace: vcf-sddc-lcm
  resourceVersion: "13213769"
  uid: 107f3f96-c4eb-47b8-8f34-9ab0b4d18e8b
spec:
  additionalVolumes:
  - mountPath: /usr/local/share/ca-certificates/client/
    name: seaweedfs-client-cert
    targetContainers:
    - postgres
    - walg
    volumeSource:
      secret:
        optional: false
        secretName: seaweedfs-client-cert
  - mountPath: /usr/local/share/ca-certificates/tls/
    name: pgbackup-sidecar-tls-cert
    targetContainers:
    - walg
    volumeSource:
      secret:
        optional: false
        secretName: vcf-sddc-lcm-db-postgres-cert-secret
  allowedSourceRanges: null
  enableConnectionPooler: false
  enableReplicaConnectionPooler: false
  env:
  - name: AWS_ACCESS_KEY_ID
    valueFrom:
      secretKeyRef:
        key: access_key
        name: vcf-sddc-lcm.db.vcf-sddc-lcm-db.wal-backup-credentials
  - name: AWS_SECRET_ACCESS_KEY
    valueFrom:
      secretKeyRef:
        key: secret_key
        name: vcf-sddc-lcm.db.vcf-sddc-lcm-db.wal-backup-credentials
  - name: AWS_ENDPOINT
    value: https://seaweedfs-s3.vmsp-platform.svc.cluster.local:8443
  - name: WALG_S3_CA_CERT_FILE
    value: /usr/local/share/ca-certificates/client/ca.crt
  - name: USE_WALG_BACKUP
    value: "true"
  - name: USE_WALG_RESTORE
    value: "true"
  - name: CLONE_USE_WALG_RESTORE
    value: "true"
  - name: CLONE_WAL_BUCKET_SCOPE_PREFIX
  - name: BACKUP_NUM_TO_RETAIN
    value: "1"
  - name: WAL_S3_BUCKET
    value: vcf-sddc-lcm.db.vcf-sddc-lcm-db.wal-backup
  - name: AWS_S3_FORCE_PATH_STYLE
    value: "true"
  - name: BACKUP_SCHEDULE
    value: '#0 25 31 2 * '
  nodeAffinity:
    preferredDuringSchedulingIgnoredDuringExecution:
    - preference:
        matchExpressions:
        - key: node.kubernetes.io/instance-type
          operator: In
          values:
          - vsphere-vm.cpu-12.mem-24gb.os-photon
      weight: 1
  numberOfInstances: 3
  patroni:
    failsafe_mode: true
    retry_timeout: 20
    synchronous_mode: true
    synchronous_mode_strict: true
    synchronous_node_count: 1
    ttl: 50
  postgresql:
    parameters:
      archive_cleanup_command: curl -sf --connect-timeout 1 --max-time 5 http://127.0.0.1:8008/replica
        > /dev/null && envdir "/run/etc/wal-e.d/env" pg_archivecleanup "/home/postgres/pgdata/pgroot/data/pg_wal"
        "%r" || exit 0
      archive_command: (curl -sf --connect-timeout 1 --max-time 5 http://127.0.0.1:8008/primary
        > /dev/null || exit 0) && envdir "/run/etc/wal-e.d/env" wal-g wal-push "%p"
      archive_timeout: 900s
      client_min_messages: error
      log_destination: stderr
      log_line_prefix: '%m %c %x %d %u %r %p %l'
      log_parameter_max_length: "0"
      log_parameter_max_length_on_error: "0"
      logging_collector: "off"
      max_connections: "500"
      password_encryption: scram-sha-256
      pgaudit.log: none
      pgaudit.log_catalog: "off"
      pgaudit.log_parameter: "off"
      restore_command: 'envdir "/run/etc/wal-e.d/env" /bin/bash -c "echo $(date -u
        +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: start %f >&2; if ! timeout 1s bash -c ''exec
        3<>/dev/tcp/seaweedfs-s3.vmsp-platform.svc.cluster.local/8443''; then echo
        $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: preflight-fail https://seaweedfs-s3.vmsp-platform.svc.cluster.local:8443
        >&2; exit 1; fi; if timeout 30s /scripts/restore_command.sh \"%f\" \"%p\";
        then if [ -s \"%p\" ]; then echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc:
        success %f >&2; exit 0; else echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC)
        rc: empty-file %f >&2; exit 1; fi; else rc=$?; if [ \"${rc:-0}\" -eq 124 ];
        then echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: fetch-timeout %f >&2;
        else echo $(date -u +%%Y-%%m-%%d_%%H:%%M:%%S_UTC) rc: fetch-fail %f rc=${rc:-?}
        >&2; fi; exit 1; fi"'
      shared_preload_libraries: bg_mon,pg_stat_statements,pgextwlist,pg_auth_mon,set_user,timescaledb,pg_cron,pg_stat_kcache
      statement_timeout: "30000"
      synchronous_commit: "on"
    version: "16"
  preparedDatabases:
    vcfsddclcmdb:
      defaultUsers: true
      schemas:
        public: {}
  resources:
    limits:
      cpu: "1"
      memory: 3048Mi
    requests:
      cpu: 500m
      memory: 512Mi
  sidecars:
  - env:
    - name: DATA_SOURCE_URI
      value: localhost:5432/postgres?sslmode=disable
    - name: DATA_SOURCE_USER
      value: $(POSTGRES_USER)
    - name: DATA_SOURCE_PASS
      value: $(POSTGRES_PASSWORD)
    image: registry.vmsp-platform.svc.cluster.local:5000/images/prometheuscommunity-postgres-exporter:v0.18.1
    name: metrics-exporter
    ports:
    - containerPort: 9187
      name: http-metrics
      protocol: TCP
  - env:
    - name: PGPORT
      value: "5432"
    - name: PGHOST
      value: vcf-sddc-lcm-db.vcf-sddc-lcm.svc.cluster.local
    - name: WALE_S3_PREFIX
      value: s3://vcf-sddc-lcm.db.vcf-sddc-lcm-db.wal-backup/spilo/vcf-sddc-lcm-vcf-sddc-lcm-db/wal/16/
    - name: AWS_ACCESS_KEY_ID
      valueFrom:
        secretKeyRef:
          key: access_key
          name: vcf-sddc-lcm.db.vcf-sddc-lcm-db.wal-backup-credentials
    - name: AWS_SECRET_ACCESS_KEY
      valueFrom:
        secretKeyRef:
          key: secret_key
          name: vcf-sddc-lcm.db.vcf-sddc-lcm-db.wal-backup-credentials
    - name: AWS_ENDPOINT
      value: https://seaweedfs-s3.vmsp-platform.svc.cluster.local:8443
    - name: WALG_S3_CA_CERT_FILE
      value: /usr/local/share/ca-certificates/client/ca.crt
    - name: USE_WALG_BACKUP
      value: "true"
    - name: USE_WALG_RESTORE
      value: "true"
    - name: CLONE_USE_WALG_RESTORE
      value: "true"
    - name: CLONE_WAL_BUCKET_SCOPE_PREFIX
    - name: BACKUP_NUM_TO_RETAIN
      value: "1"
    - name: WAL_S3_BUCKET
      value: vcf-sddc-lcm.db.vcf-sddc-lcm-db.wal-backup
    - name: AWS_S3_FORCE_PATH_STYLE
      value: "true"
    - name: BACKUP_SCHEDULE
      value: '#0 25 31 2 * '
    image: registry.vmsp-platform.svc.cluster.local:5000/images/pgbackup:v1.0.0
    name: walg
    ports:
    - containerPort: 9100
      name: walg
      protocol: TCP
    resources:
      limits:
        cpu: 1000m
        memory: 768Mi
      requests:
        cpu: 100m
        memory: 100Mi
  teamId: vcf-sddc-lcm-db
  tls:
    caFile: ca.crt
    secretName: vcf-sddc-lcm-db-postgres-cert-secret
  users:
    postgres:
    - superuser
    - createdb
  volume:
    size: 30Gi
status:
  PostgresClusterStatus: Running

The RaaS instance is quite over provisioned

An example of what mine was running at

NAME                     CPU(cores)   MEMORY(bytes)
pgdatabase-0             43m          790Mi
raas-5857f54b4f-l4zb4    20m          716Mi
redis-6cccfb46f4-gp7p6   6m           7Mi

The current requests are

RaaS – 1000m/1536MiB
Redis – 500m/500MiB
Postgres – 1200m/2248MiB

So these are very over provisioned, we can set them to the following, Request and Limits as
Raas – 250m/1024MiB
Redis – 100m/128MiB
Postgres – 250m/768MiB – 500m/1536MiB

Raas

kubectl patch deployment raas -n salt-raas --type='json' -p='[
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/requests/cpu", "value": "250m"},
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/requests/memory", "value": "1Gi"},
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/limits/memory", "value": "1Gi"}
]'

Redis

kubectl patch deployment redis -n salt-raas --type='json' -p='[
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/requests/cpu", "value": "100m"},
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/requests/memory", "value": "128Mi"},
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/limits/memory", "value": "128Mi"}
]'

Postgres

kubectl patch postgresinstance pgdatabase -n salt-raas --type='json' -p='[
  {"op": "replace", "path": "/spec/resources/requests/cpu", "value": "250m"},
  {"op": "replace", "path": "/spec/resources/requests/memory", "value": "768Mi"},
  {"op": "replace", "path": "/spec/resources/limits/cpu", "value": "500m"},
  {"op": "replace", "path": "/spec/resources/limits/memory", "value": "1536Mi"}
]'

We then need to delete the pod to force the changes to be picked up with

kubectl delete pod pgdatabase-0 -n salt-raas

The Master instance is quite over provisioned

An example of what mine was running at

NAME                           CPU(cores)   MEMORY(bytes)
salt-master-8674dd877b-8j6q2   16m          912Mi
salt-minion-6c58844558-zkxqf   3m           91Mi

The current requests are

Master – 500m/1024MiB
Minion – 500m/500MiB

So these are very over provisioned, we can set them to the following, Request and Limits as
Master – 250m/1024MiB – 500m
Minion – 100m/256MiB

Master

kubectl patch deployment salt-master -n salt --type='json' -p='[
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/requests/cpu", "value": "250m"},
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/limits/cpu", "value": "500m"}
]'

Minion

kubectl patch deployment salt-minion -n salt --type='json' -p='[
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/requests/cpu", "value": "100m"},
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/requests/memory", "value": "256Mi"},
  {"op": "replace", "path": "/spec/template/spec/containers/0/resources/limits/memory", "value": "256Mi"}
]'

apiVersion: apps/v1
kind: StatefulSet
metadata:
  annotations:
    meta.helm.sh/release-name: zot-1
    meta.helm.sh/release-namespace: vmsp-platform
    reloader.vmsp.vmware.com/auto: "true"
  creationTimestamp: "2026-05-12T12:46:29Z"
  generation: 2
  labels:
    app.kubernetes.io/instance: zot-1
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: zot
    app.kubernetes.io/version: v2.1.11
    helm.sh/chart: zot-0.1.68-34
    helm.toolkit.fluxcd.io/name: zot-1
    helm.toolkit.fluxcd.io/namespace: vmsp-platform
    ops.vmsp.vmware.com/type: registry-service
  name: zot-1
  namespace: vmsp-platform
  resourceVersion: "13209559"
  uid: afa14b9d-52f7-4098-bbf0-f458d3cc51df
spec:
  minReadySeconds: 10
  persistentVolumeClaimRetentionPolicy:
    whenDeleted: Retain
    whenScaled: Retain
  podManagementPolicy: OrderedReady
  replicas: 1
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      app.kubernetes.io/instance: zot-1
      app.kubernetes.io/name: zot
  serviceName: ""
  template:
    metadata:
      annotations:
        checksum/config: 0a98204231fad36afb0c28360a385ad1090e9094feff5d18e517fe5411a4042f
        vmsp.vmware.com/triggerrestart: "13967"
      labels:
        app.kubernetes.io/component: zot
        app.kubernetes.io/instance: zot-1
        app.kubernetes.io/name: zot
        ops.vmsp.vmware.com/type: registry-service
    spec:
      affinity:
        podAntiAffinity:
          preferredDuringSchedulingIgnoredDuringExecution:
          - podAffinityTerm:
              labelSelector:
                matchExpressions:
                - key: app.kubernetes.io/name
                  operator: In
                  values:
                  - zot
              topologyKey: kubernetes.io/hostname
            weight: 100
      containers:
      - image: registry.vmsp-platform.svc.cluster.local:5000/images/zot:v2.1.11
        imagePullPolicy: IfNotPresent
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /livez
            port: 5000
            scheme: HTTPS
          initialDelaySeconds: 5
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        name: zot
        ports:
        - containerPort: 5000
          name: zot
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /readyz
            port: 5000
            scheme: HTTPS
          initialDelaySeconds: 5
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        resources:
          limits:
            ephemeral-storage: 1Gi
            memory: 700Mi
          requests:
            cpu: 350m
            ephemeral-storage: 512Mi
            memory: 600Mi
        securityContext:
          runAsNonRoot: true
        startupProbe:
          failureThreshold: 3
          httpGet:
            path: /startupz
            port: 5000
            scheme: HTTPS
          initialDelaySeconds: 5
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /var/lib/registry
          name: zot-1-pvc
        - mountPath: /etc/zot
          name: zot-1-config
        - mountPath: /secret
          name: zot-htpasswd-secret
        - mountPath: /certs
          name: certificate
          readOnly: true
        - mountPath: /creds
          name: sync-creds
      dnsPolicy: ClusterFirst
      priorityClassName: system-cluster-critical
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext:
        fsGroup: 65534
        runAsGroup: 65534
        runAsNonRoot: true
        runAsUser: 65534
      serviceAccount: zot-1
      serviceAccountName: zot-1
      terminationGracePeriodSeconds: 30
      volumes:
      - configMap:
          defaultMode: 420
          name: zot-1-config
        name: zot-1-config
      - name: zot-htpasswd-secret
        secret:
          defaultMode: 420
          secretName: zot-htpasswd-secret
      - name: certificate
        secret:
          defaultMode: 420
          secretName: registry-certificate
      - configMap:
          defaultMode: 420
          name: zot-sync-credentials
        name: sync-creds
  updateStrategy:
    rollingUpdate:
      partition: 0
    type: RollingUpdate
  volumeClaimTemplates:
  - apiVersion: v1
    kind: PersistentVolumeClaim
    metadata:
      name: zot-1-pvc
    spec:
      accessModes:
      - ReadWriteOnce
      resources:
        requests:
          storage: 75Gi
      storageClassName: vmsp-default
      volumeMode: Filesystem
    status:
      phase: Pending
status:
  availableReplicas: 1
  collisionCount: 0
  currentReplicas: 1
  currentRevision: zot-1-64cf7c8845
  observedGeneration: 2
  readyReplicas: 1
  replicas: 1
  updateRevision: zot-1-64cf7c8845
  updatedReplicas: 1

apiVersion: apps/v1
kind: Deployment
metadata:
  annotations:
    deployment.kubernetes.io/revision: "2"
    meta.helm.sh/release-name: depot-service
    meta.helm.sh/release-namespace: vcf-fleet-depot
    reloader.vmsp.vmware.com/auto: "true"
    reloader.vmsp.vmware.com/exclusion.secret: depot-service-secret
  creationTimestamp: "2026-05-12T13:39:13Z"
  generation: 2
  labels:
    app: depot-service
    app.kubernetes.io/instance: depot-service
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: depot-service
    app.kubernetes.io/version: 9.1.0
    component.vmsp.vmware.com/type: vcf-fleet-depot
    helm.sh/chart: depot-service-9.1.0-0_25371105
    helm.toolkit.fluxcd.io/name: depot-service
    helm.toolkit.fluxcd.io/namespace: vcf-fleet-depot
    ops.vmsp.vmware.com/type: vcf-depot-service
  name: depot-service
  namespace: vcf-fleet-depot
  resourceVersion: "13212166"
  uid: 8b151d0c-0877-4355-99da-e73673a5cfb6
spec:
  progressDeadlineSeconds: 600
  replicas: 1
  revisionHistoryLimit: 5
  selector:
    matchLabels:
      app: depot-service
      app.kubernetes.io/instance: depot-service
      app.kubernetes.io/name: depot-service
      component.vmsp.vmware.com/type: vcf-fleet-depot
  strategy:
    type: Recreate
  template:
    metadata:
      annotations:
        vmsp.vmware.com/triggerrestart: "50227"
      labels:
        app: depot-service
        app.kubernetes.io/instance: depot-service
        app.kubernetes.io/name: depot-service
        component.vmsp.vmware.com/type: vcf-fleet-depot
        ops.vmsp.vmware.com/type: vcf-depot-service-instance
    spec:
      containers:
      - env:
        - name: DEPOT_TYPE
          valueFrom:
            secretKeyRef:
              key: depotType
              name: depot-service-secret
        - name: OFFLINE_DEPOT_ORIGIN
          valueFrom:
            secretKeyRef:
              key: offlineOrigin
              name: depot-service-secret
        - name: OFFLINE_DEPOT_BASE_PATH
          valueFrom:
            secretKeyRef:
              key: offlineBasePath
              name: depot-service-secret
        - name: OFFLINE_DEPOT_USERNAME
          valueFrom:
            secretKeyRef:
              key: offlineUsername
              name: depot-service-secret
        - name: OFFLINE_DEPOT_PASSWORD
          valueFrom:
            secretKeyRef:
              key: offlinePassword
              name: depot-service-secret
        - name: DEPOT_SERVICE_SERVICE_FQDN
          value: depot-service.vcf-fleet-depot.svc.cluster.local
        - name: DISTRIBUTION_SERVICE_HOST
          value: distribution-service.vcf-fleet-depot.svc.cluster.local
        - name: PROXY_FORWARDER_HOST
          value: 127.0.0.1
        - name: SERVER_HTTPS_PORT
          value: "7443"
        - name: DNS_RESOLVER
          value: kube-dns.kube-system.svc.cluster.local
        - name: SKIP_PROXY_FORWARDER
          value: "false"
        - name: PUBLIC_DEPOT_HOST
          value: dl.broadcom.com
        - name: PUBLIC_VVS_HOST
          value: vvs.broadcom.com
        - name: PUBLIC_VSAN_HCL_HOST
          value: eapi.broadcom.com
        - name: PUBLIC_PACKAGES_HOST
          value: projects.packages.broadcom.com
        - name: OFFLINE_OCI_WRITE_ENABLED
          value: "false"
        - name: OCI_REPO_PATH_MAPPINGS_OVERRIDE
          value: '[]'
        - name: PUBLIC_VVS_VCF_LCM_BUNDLE_PATH
          value: /v1/products/bundles/type/vcf-lcm-v2-bundle
        - name: PUBLIC_VVS_VCF_INTEROP_BUNDLE_PATH
          value: /v1/products/bundles/type/vcf-interop-bundle
        - name: PUBLIC_VVS_VLCM_INTEROP_VCG_BUNDLE_PATH
          value: /v1/products/bundles/vlcm-compatibility-data/v1/vlcm-interop-vcg-bundle
        - name: CONFIG_WORKER_CONNECTIONS
          value: "1024"
        - name: CONFIG_WORKER_RLIMIT_NOFILE
          value: "4096"
        - name: CONFIG_SEND_TIMEOUT
          value: 300s
        - name: CONFIG_OUTPUT_BUFFERS
          value: 2 512k
        - name: CONFIG_RATE_LIMIT_ZONE
          value: downloads:10m rate=100r/s
        - name: CONFIG_RATE_LIMIT_BURST
          value: "100"
        - name: DISABLE_CACHE
          value: "false"
        - name: CONFIG_CACHE_INACTIVE
          value: 365d
        - name: CONFIG_CACHE_KEYS_ZONE_SIZE
          value: 100m
        - name: CONFIG_CACHE_LOCK_AGE
          value: 3600s
        - name: CONFIG_CACHE_LOCK_TIMEOUT
          value: 60s
        - name: CONFIG_CACHE_MAX_SIZE
          value: 950g
        - name: CONFIG_CACHE_VALID_BINARIES
          value: 200 365d
        - name: CONFIG_CACHE_REVALIDATE_BINARIES
          value: "off"
        - name: CONFIG_CACHE_REVALIDATE_METADATA
          value: "on"
        - name: CONFIG_CACHE_EXCLUDE_FILE_EXTENSIONS
          value: json,yaml,xml,yml,xml.sha256,json.sha256,xml.sign,json.sign,xml.sig
        - name: CONFIG_PROXY_MAX_TEMP_FILE_SIZE
          value: "0"
        - name: CONFIG_SSL_SESSION_CACHE
          value: shared:SSL:50m
        - name: CONFIG_SSL_SESSION_TIMEOUT
          value: 1d
        - name: CONFIG_PROXY_SSL_SESSION_REUSE
          value: "on"
        - name: CONFIG_PROXY_READ_TIMEOUT
          value: "300"
        image: registry.vmsp-platform.svc.cluster.local:5000/images/file-server:9.1.0-0_25371105
        imagePullPolicy: Always
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /internal/api/content-gateway/v1/health
            port: 7443
            scheme: HTTPS
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        name: file-server
        ports:
        - containerPort: 7443
          name: fs-https
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /internal/api/content-gateway/v1/health
            port: 7443
            scheme: HTTPS
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        resources:
          limits:
            memory: 1Gi
          requests:
            cpu: 300m
            memory: 512Mi
        securityContext:
          allowPrivilegeEscalation: false
          capabilities:
            add:
            - CHOWN
            - SETGID
            - SETUID
            drop:
            - ALL
          privileged: false
        startupProbe:
          failureThreshold: 60
          httpGet:
            path: /internal/api/content-gateway/v1/health
            port: 7443
            scheme: HTTPS
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /data
          name: data-volume
          subPath: data
        - mountPath: /etc/service/trust
          name: vcf-fleet-depot-certificate
          readOnly: true
        - mountPath: /etc/platform/trust
          name: platform-trust
          readOnly: true
        - mountPath: /etc/service/secret/depot-service-secret
          name: depot-service-secret
          readOnly: true
      - env:
        - name: PLATFORM_TRUST
          value: /etc/platform/trust
        - name: BCF_TRUSTSTORE_PATH
          value: /etc/platform/java/fips/bundle.bcfks
        - name: JAVA_TRUSTSTORE_FILE_NAME
          value: bundle.jks
        - name: SERVER_CERT_DIR
          value: /etc/service/trust
        - name: SERVER_CERT_FILE
          value: tls.crt
        - name: SERVER_KEY_FILE
          value: tls.key
        - name: BCF_SERVER_KEYSTORE_PATH
          value: /etc/platform/java/fips/tls.bcfks
        - name: PEER_PROXY_CERT_DIR
          value: /etc/platform/peer-proxy-certs
        - name: PEER_PROXY_CERT_FILENAME
          value: https_proxy.pem
        - name: SPRING_PROFILES_ACTIVE
          value: depot
        - name: SPRING_PROFILES_INCLUDE
          value: override
        - name: VCF_USE_RESOURCE_BUNDLE_LOCALIZATION
          value: "true"
        - name: KUBERNETES_CLUSTER_DOMAIN
          value: svc.cluster.local
        - name: KUBERNETES_SERVICE_ACCOUNT_PATH
          value: /etc/service/secret/depot-service-secret
        - name: DEPOT_SERVICE_NAME
          value: depot-service
        - name: DEPOT_SERVICE_SECRET_NAME
          value: depot-service-secret
        - name: DEPOT_SERVICE_SERVICE_FQDN
          value: depot-service.vcf-fleet-depot.svc.cluster.local
        envFrom:
        - configMapRef:
            name: download-service-configs
        image: registry.vmsp-platform.svc.cluster.local:5000/images/download-service:9.1.0-0_25371105
        imagePullPolicy: Always
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /depot-service/api/depot/v1/health/livenessState
            port: 8443
            scheme: HTTPS
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        name: download-service
        ports:
        - containerPort: 8080
          name: ds-http
          protocol: TCP
        - containerPort: 8443
          name: ds-https
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /depot-service/api/depot/v1/health/readinessState
            port: 8443
            scheme: HTTPS
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        resources:
          limits:
            memory: 1Gi
          requests:
            cpu: 300m
            memory: 512Mi
        securityContext:
          allowPrivilegeEscalation: false
          capabilities:
            add:
            - CHOWN
            - SETGID
            - SETUID
            drop:
            - ALL
          privileged: false
        startupProbe:
          failureThreshold: 60
          httpGet:
            path: /depot-service/api/depot/v1/health/ping
            port: 8443
            scheme: HTTPS
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /data
          name: data-volume
          subPath: data
        - mountPath: /etc/config
          name: config-volume
        - mountPath: /etc/platform/peer-proxy-service-config
          name: peer-proxy-config
          readOnly: true
        - mountPath: /etc/platform/peer-proxy-certs
          name: proxy-peer-certificate
          readOnly: true
        - mountPath: /etc/platform/peer-proxy-credentials
          name: proxy-peer-credentials
          readOnly: true
        - mountPath: /etc/service/trust
          name: vcf-fleet-depot-certificate
          readOnly: true
        - mountPath: /etc/platform/trust
          name: platform-trust
          readOnly: true
        - mountPath: /etc/service/secret/depot-service-secret
          name: depot-service-secret
          readOnly: true
        - mountPath: /etc/vmware/feature-state-switches
          name: feature-state-switches-volume
          readOnly: true
      - env:
        - name: LISTEN_PORT
          value: "9080"
        - name: PROXY_HOST
        - name: PROXY_PORT
        - name: PROXY_SCHEME
          value: http
        - name: PROXY_CREDENTIALS_ENABLED
          value: "false"
        - name: PROXY_USERNAME
          valueFrom:
            secretKeyRef:
              key: username
              name: proxy-service-credentials
              optional: true
        - name: PROXY_PASSWORD
          valueFrom:
            secretKeyRef:
              key: password
              name: proxy-service-credentials
              optional: true
        - name: PROXY_CERTIFICATE
          valueFrom:
            secretKeyRef:
              key: https_proxy.pem
              name: proxy-service-peer-certificate
              optional: true
        - name: PLATFORM_TRUST_BUNDLE
          value: /etc/platform/trust/bundle.pem
        - name: OFFLINE_DEPOT_CERTIFICATES_PATH
          value: /etc/depot/trust/certificates.pem
        - name: DEPOT_SERVICE_SERVICE_FQDN
          value: depot-service.vcf-fleet-depot.svc.cluster.local
        - name: DISABLE_PROXY
          value: "false"
        image: registry.vmsp-platform.svc.cluster.local:5000/images/proxy-forwarder:9.1.0-0_25371105
        imagePullPolicy: Always
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /internal/api/proxy-forwarder/v1/health
            port: 9080
            scheme: HTTP
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        name: proxy-forwarder
        ports:
        - containerPort: 9080
          name: pf-http
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /internal/api/proxy-forwarder/v1/health
            port: 9080
            scheme: HTTP
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        resources:
          limits:
            memory: 320Mi
          requests:
            cpu: 300m
            memory: 256Mi
        securityContext:
          allowPrivilegeEscalation: false
          capabilities:
            add:
            - CHOWN
            - SETGID
            - SETUID
            drop:
            - ALL
          privileged: false
        startupProbe:
          failureThreshold: 60
          httpGet:
            path: /internal/api/proxy-forwarder/v1/health
            port: 9080
            scheme: HTTP
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /etc/platform/trust
          name: platform-trust
          readOnly: true
        - mountPath: /etc/depot/trust
          name: offline-depot-certificates
          readOnly: true
      dnsPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      serviceAccount: depot-service-service-account
      serviceAccountName: depot-service-service-account
      terminationGracePeriodSeconds: 30
      volumes:
      - configMap:
          defaultMode: 420
          name: peer-proxy-config
          optional: true
        name: peer-proxy-config
      - name: proxy-peer-certificate
        secret:
          defaultMode: 420
          optional: true
          secretName: proxy-service-peer-certificate
      - name: proxy-peer-credentials
        secret:
          defaultMode: 420
          optional: true
          secretName: proxy-service-credentials
      - name: data-volume
        persistentVolumeClaim:
          claimName: depotservice-data-pvc
      - configMap:
          defaultMode: 420
          name: download-service-configs
        name: config-volume
      - name: vcf-fleet-depot-certificate
        secret:
          defaultMode: 420
          secretName: depot-service-intra-cert
      - configMap:
          defaultMode: 420
          name: platform-trust
        name: platform-trust
      - name: depot-service-secret
        secret:
          defaultMode: 420
          secretName: depot-service-secret
      - name: offline-depot-certificates
        secret:
          defaultMode: 420
          items:
          - key: offlineCertificate
            path: certificates.pem
          optional: true
          secretName: depot-service-secret
      - configMap:
          defaultMode: 420
          name: feature-state-switches
        name: feature-state-switches-volume
status:
  availableReplicas: 1
  conditions:
  - lastTransitionTime: "2026-05-12T13:39:13Z"
    lastUpdateTime: "2026-05-12T14:03:31Z"
    message: ReplicaSet "depot-service-77cb99b56b" has successfully progressed.
    reason: NewReplicaSetAvailable
    status: "True"
    type: Progressing
  - lastTransitionTime: "2026-05-27T06:15:00Z"
    lastUpdateTime: "2026-05-27T06:15:00Z"
    message: Deployment has minimum availability.
    reason: MinimumReplicasAvailable
    status: "True"
    type: Available
  observedGeneration: 2
  readyReplicas: 1
  replicas: 1
  updatedReplicas: 1

apiVersion: apps/v1
kind: Deployment
metadata:
  annotations:
    deployment.kubernetes.io/revision: "2"
    meta.helm.sh/release-name: distribution-service
    meta.helm.sh/release-namespace: vcf-fleet-depot
    reloader.vmsp.vmware.com/auto: "true"
  creationTimestamp: "2026-05-12T13:38:43Z"
  generation: 2
  labels:
    app: distribution-service
    app.kubernetes.io/component: distribution-service
    app.kubernetes.io/instance: distribution-service
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: distribution-service
    app.kubernetes.io/version: 9.1.0
    helm.sh/chart: distribution-service-9.1.0-0_25371105
    helm.toolkit.fluxcd.io/name: distribution-service
    helm.toolkit.fluxcd.io/namespace: vcf-fleet-depot
    ops.vmsp.vmware.com/type: vcf-distribution-service
  name: distribution-service
  namespace: vcf-fleet-depot
  resourceVersion: "13209944"
  uid: 9b0c4088-29fa-44fc-b577-0af811ec60eb
spec:
  progressDeadlineSeconds: 600
  replicas: 1
  revisionHistoryLimit: 5
  selector:
    matchLabels:
      app.kubernetes.io/component: distribution-service
      app.kubernetes.io/instance: distribution-service
      app.kubernetes.io/name: distribution-service
  strategy:
    type: Recreate
  template:
    metadata:
      annotations:
        checksum/init-config: 9035ec91c56485b6d0bb0367988735b7afd40a05d63b49b752241482381daaca
        vmsp.vmware.com/triggerrestart: "50227"
      labels:
        app: distribution-service
        app.kubernetes.io/component: distribution-service
        app.kubernetes.io/instance: distribution-service
        app.kubernetes.io/name: distribution-service
        ops.vmsp.vmware.com/type: vcf-distribution-service-instance
    spec:
      containers:
      - image: registry.vmsp-platform.svc.cluster.local:5000/images/distribution-service:9.1.0-0_25371105
        imagePullPolicy: Always
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /
            port: 5443
            scheme: HTTPS
          periodSeconds: 30
          successThreshold: 1
          timeoutSeconds: 5
        name: distribution-service
        ports:
        - containerPort: 18080
          name: distr-http
          protocol: TCP
        - containerPort: 18443
          name: distr-https
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /
            port: 5443
            scheme: HTTPS
          periodSeconds: 120
          successThreshold: 1
          timeoutSeconds: 5
        resources:
          limits:
            memory: 1Gi
          requests:
            cpu: 500m
            memory: 512Mi
        securityContext:
          allowPrivilegeEscalation: false
          capabilities:
            add:
            - CHOWN
            - SETGID
            - SETUID
            drop:
            - ALL
          privileged: false
        startupProbe:
          failureThreshold: 30
          httpGet:
            path: /
            port: 5443
            scheme: HTTPS
          periodSeconds: 15
          successThreshold: 1
          timeoutSeconds: 5
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /var/lib/registry
          name: distributionservice-data-pvc
        - mountPath: /etc/docker/registry
          name: config-dir
        - mountPath: /certs
          name: distribution-certificate
          readOnly: true
        - mountPath: /etc/platform/trust
          name: platform-trust
          readOnly: true
      dnsPolicy: ClusterFirst
      initContainers:
      - args:
        - /etc/scripts/init-config.sh
        command:
        - /bin/sh
        image: registry.vmsp-platform.svc.cluster.local:5000/images/distribution-service:9.1.0-0_25371105
        imagePullPolicy: Always
        name: distribution-service-init
        resources: {}
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /etc/docker/registry
          name: config-dir
        - mountPath: /etc/scripts
          name: init-config
        - mountPath: /certs
          name: distribution-certificate
          readOnly: true
        - mountPath: /etc/platform/trust
          name: platform-trust
          readOnly: true
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      terminationGracePeriodSeconds: 30
      volumes:
      - name: distributionservice-data-pvc
        persistentVolumeClaim:
          claimName: distributionservice-data-pvc
      - emptyDir: {}
        name: config-dir
      - configMap:
          defaultMode: 493
          name: distribution-service-init-config
        name: init-config
      - emptyDir: {}
        name: registry-workdir
      - name: distribution-certificate
        secret:
          defaultMode: 420
          secretName: distribution-intra-cert
      - configMap:
          defaultMode: 420
          name: platform-trust
        name: platform-trust
status:
  availableReplicas: 1
  conditions:
  - lastTransitionTime: "2026-05-12T13:38:43Z"
    lastUpdateTime: "2026-05-12T14:00:57Z"
    message: ReplicaSet "distribution-service-84574b5cd" has successfully progressed.
    reason: NewReplicaSetAvailable
    status: "True"
    type: Progressing
  - lastTransitionTime: "2026-05-27T06:12:21Z"
    lastUpdateTime: "2026-05-27T06:12:21Z"
    message: Deployment has minimum availability.
    reason: MinimumReplicasAvailable
    status: "True"
    type: Available
  observedGeneration: 2
  readyReplicas: 1
  replicas: 1
  updatedReplicas: 1

apiVersion: apps/v1
kind: Deployment
metadata:
  annotations:
    deployment.kubernetes.io/revision: "1"
    meta.helm.sh/release-name: telemetry-acceptor
    meta.helm.sh/release-namespace: telemetry
    reloader.vmsp.vmware.com/auto: "true"
    reloader.vmsp.vmware.com/exclusion.configmap: ceip
    reloader.vmsp.vmware.com/exclusion.secret: telemetry-config
  creationTimestamp: "2026-05-12T14:30:06Z"
  generation: 1
  labels:
    app.kubernetes.io/instance: telemetry-acceptor
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: telemetry-acceptor
    app.kubernetes.io/version: 1.16.0
    helm.sh/chart: telemetry-acceptor-9.1.0-25181946
    helm.toolkit.fluxcd.io/name: telemetry-acceptor
    helm.toolkit.fluxcd.io/namespace: telemetry
    ops.vmsp.vmware.com/type: telemetry-acceptor-service
  name: telemetry-acceptor
  namespace: telemetry
  resourceVersion: "13208066"
  uid: f65038fe-8e4f-467b-b7f1-090efb8069b6
spec:
  progressDeadlineSeconds: 600
  replicas: 1
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      app.kubernetes.io/instance: telemetry-acceptor
      app.kubernetes.io/name: telemetry-acceptor
  strategy:
    rollingUpdate:
      maxSurge: 25%
      maxUnavailable: 50%
    type: RollingUpdate
  template:
    metadata:
      labels:
        app.kubernetes.io/instance: telemetry-acceptor
        app.kubernetes.io/managed-by: Helm
        app.kubernetes.io/name: telemetry-acceptor
        app.kubernetes.io/version: 1.16.0
        helm.sh/chart: telemetry-acceptor-9.1.0-25181946
        ops.vmsp.vmware.com/type: telemetry-acceptor-service-resource
    spec:
      affinity:
        podAntiAffinity:
          preferredDuringSchedulingIgnoredDuringExecution:
          - podAffinityTerm:
              labelSelector:
                matchExpressions:
                - key: app
                  operator: In
                  values:
                  - telemetry-acceptor
              topologyKey: kubernetes.io/hostname
            weight: 100
      containers:
      - env:
        - name: LOG_LEVEL
          value: INFO
        - name: SERVER_PORT
          value: "1081"
        - name: MANAGEMENT_SERVER_PORT
          value: "9091"
        - name: JAVA_TOOL_OPTIONS
          value: |
            -XX:+UseContainerSupport -XX:MaxRAMPercentage="75" -XX:InitialRAMPercentage="50"
        - name: COMPONENT_ID
          value: da545315-0aa9-49c3-b136-f17294358bbc
        - name: COMPONENT_TYPE
          value: telemetry-acceptor
        - name: COMPONENT_VERSION
          value: 9.1.0.0.25181946
        - name: POD_NAME
          valueFrom:
            fieldRef:
              apiVersion: v1
              fieldPath: metadata.name
        - name: NAMESPACE
          valueFrom:
            fieldRef:
              apiVersion: v1
              fieldPath: metadata.namespace
        - name: VSP_PROXY_HOST
          valueFrom:
            secretKeyRef:
              key: host
              name: vmsp-proxy-service-secret
              optional: true
        - name: VSP_PROXY_PORT
          valueFrom:
            secretKeyRef:
              key: port
              name: vmsp-proxy-service-secret
              optional: true
        - name: VSP_PROXY_USERNAME
          valueFrom:
            secretKeyRef:
              key: username
              name: vmsp-proxy-service-secret
              optional: true
        - name: VSP_PROXY_PASSWORD
          valueFrom:
            secretKeyRef:
              key: password
              name: vmsp-proxy-service-secret
              optional: true
        - name: VSP_PROXY_SCHEME
          valueFrom:
            secretKeyRef:
              key: scheme
              name: vmsp-proxy-service-secret
              optional: true
        - name: SERVER_SSL_ENABLED
          value: "true"
        - name: SERVER_SSL_CERTIFICATE
          value: file:/etc/tls/tls.crt
        - name: SERVER_SSL_CERTIFICATE_PRIVATE_KEY
          value: file:/etc/tls/tls.key
        - name: SERVER_HTTP_ENABLED
          value: "true"
        - name: SERVER_HTTP_PORT
          value: "8080"
        image: registry.vmsp-platform.svc.cluster.local:5000/images/telemetry-acceptor/9.1.0.0.25181946/telemetry-acceptor/telemetry-acceptor:9.1.0.0.25181946
        imagePullPolicy: IfNotPresent
        livenessProbe:
          failureThreshold: 30
          httpGet:
            path: /debug/health/liveness
            port: 9091
            scheme: HTTP
          periodSeconds: 5
          successThreshold: 1
          timeoutSeconds: 1
        name: telemetry-acceptor
        ports:
        - containerPort: 1081
          name: https
          protocol: TCP
        - containerPort: 8080
          name: http
          protocol: TCP
        - containerPort: 9091
          name: management
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /debug/health/readiness
            port: 9091
            scheme: HTTP
          periodSeconds: 5
          successThreshold: 1
          timeoutSeconds: 1
        resources:
          limits:
            cpu: "1"
            memory: 1Gi
          requests:
            cpu: 500m
            memory: 512Mi
        securityContext:
          allowPrivilegeEscalation: false
          capabilities:
            drop:
            - ALL
          readOnlyRootFilesystem: true
          runAsNonRoot: true
          runAsUser: 65532
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /etc/telemetry-config
          name: telemetry-config-volume
          readOnly: true
        - mountPath: /etc/ceip
          name: ceip-volume
          readOnly: true
        - mountPath: /etc/tls
          name: tls-cert
          readOnly: true
        - mountPath: /tmp
          name: tmp-volume
      dnsPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext:
        fsGroup: 65532
        runAsGroup: 65532
        runAsNonRoot: true
        runAsUser: 65532
      terminationGracePeriodSeconds: 30
      volumes:
      - name: telemetry-config-volume
        secret:
          defaultMode: 420
          secretName: telemetry-config
      - configMap:
          defaultMode: 420
          name: ceip
        name: ceip-volume
      - name: tls-cert
        secret:
          defaultMode: 420
          secretName: telemetry-acceptor-tls
      - emptyDir: {}
        name: tmp-volume
status:
  availableReplicas: 1
  conditions:
  - lastTransitionTime: "2026-05-12T14:30:06Z"
    lastUpdateTime: "2026-05-12T14:30:28Z"
    message: ReplicaSet "telemetry-acceptor-79746d45c6" has successfully progressed.
    reason: NewReplicaSetAvailable
    status: "True"
    type: Progressing
  - lastTransitionTime: "2026-05-27T06:11:51Z"
    lastUpdateTime: "2026-05-27T06:11:51Z"
    message: Deployment has minimum availability.
    reason: MinimumReplicasAvailable
    status: "True"
    type: Available
  observedGeneration: 1
  readyReplicas: 1
  replicas: 1
  updatedReplicas: 1

apiVersion: apps/v1
kind: Deployment
metadata:
  annotations:
    deployment.kubernetes.io/revision: "1"
    meta.helm.sh/release-name: cluster-autoscaler
    meta.helm.sh/release-namespace: vmsp-platform
  creationTimestamp: "2026-05-12T12:59:50Z"
  generation: 1
  labels:
    app.kubernetes.io/instance: cluster-autoscaler
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: clusterapi-cluster-autoscaler
    helm.sh/chart: cluster-autoscaler-9.5.1
    helm.toolkit.fluxcd.io/name: cluster-autoscaler
    helm.toolkit.fluxcd.io/namespace: vmsp-platform
  name: cluster-autoscaler-clusterapi-cluster-autoscaler
  namespace: vmsp-platform
  resourceVersion: "13190340"
  uid: 9cc9caab-a879-44ea-b3a4-95ee66480edb
spec:
  progressDeadlineSeconds: 600
  replicas: 1
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      app.kubernetes.io/instance: cluster-autoscaler
      app.kubernetes.io/name: clusterapi-cluster-autoscaler
  strategy:
    rollingUpdate:
      maxSurge: 25%
      maxUnavailable: 25%
    type: RollingUpdate
  template:
    metadata:
      labels:
        app.kubernetes.io/instance: cluster-autoscaler
        app.kubernetes.io/name: clusterapi-cluster-autoscaler
    spec:
      containers:
      - command:
        - ./cluster-autoscaler
        - --cloud-provider=clusterapi
        - --namespace=vmsp-platform
        - --node-group-auto-discovery=clusterapi:clusterName=aerosphere
        - --enforce-node-group-min-size=true
        - --leader-elect=false
        - --logtostderr=true
        - --scan-interval=60s
        - --stderrthreshold=info
        - --v=4
        env:
        - name: POD_NAMESPACE
          valueFrom:
            fieldRef:
              apiVersion: v1
              fieldPath: metadata.namespace
        - name: SERVICE_ACCOUNT
          valueFrom:
            fieldRef:
              apiVersion: v1
              fieldPath: spec.serviceAccountName
        image: registry.vmsp-platform.svc.cluster.local:5000/images/cluster-autoscaler:v1.34.0
        imagePullPolicy: IfNotPresent
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /health-check
            port: 8085
            scheme: HTTP
          periodSeconds: 10
          successThreshold: 1
          timeoutSeconds: 1
        name: clusterapi-cluster-autoscaler
        ports:
        - containerPort: 8085
          protocol: TCP
        resources:
          limits:
            memory: 1Gi
          requests:
            cpu: 10m
            memory: 100Mi
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
      dnsPolicy: ClusterFirst
      priorityClassName: system-cluster-critical
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      serviceAccount: cluster-autoscaler-clusterapi-cluster-autoscaler
      serviceAccountName: cluster-autoscaler-clusterapi-cluster-autoscaler
      terminationGracePeriodSeconds: 30
status:
  availableReplicas: 1
  conditions:
  - lastTransitionTime: "2026-05-12T12:59:50Z"
    lastUpdateTime: "2026-05-12T12:59:53Z"
    message: ReplicaSet "cluster-autoscaler-clusterapi-cluster-autoscaler-7c7b8d4c99"
      has successfully progressed.
    reason: NewReplicaSetAvailable
    status: "True"
    type: Progressing
  - lastTransitionTime: "2026-05-26T07:06:44Z"
    lastUpdateTime: "2026-05-26T07:06:44Z"
    message: Deployment has minimum availability.
    reason: MinimumReplicasAvailable
    status: "True"
    type: Available
  observedGeneration: 1
  readyReplicas: 1
  replicas: 1
  updatedReplicas: 1

apiVersion: cluster.x-k8s.io/v1beta2
kind: MachineDeployment
metadata:
  annotations:
    cluster.x-k8s.io/cluster-api-autoscaler-node-group-max-size: "20"
    cluster.x-k8s.io/cluster-api-autoscaler-node-group-min-size: "3"
    machinedeployment.clusters.x-k8s.io/revision: "1"
  creationTimestamp: "2026-05-12T12:51:25Z"
  finalizers:
  - cluster.x-k8s.io/machinedeployment
  - machinedeployment.topology.cluster.x-k8s.io
  generation: 17
  labels:
    cluster.x-k8s.io/cluster-name: aerosphere
    topology.cluster.x-k8s.io/deployment-name: default
    topology.cluster.x-k8s.io/owned: ""
  name: aerosphere-default-szs5k
  namespace: vmsp-platform
  ownerReferences:
  - apiVersion: cluster.x-k8s.io/v1beta2
    kind: Cluster
    name: aerosphere
    uid: f2eca7f5-de56-4500-8a7c-bf295ef842d3
  resourceVersion: "13209883"
  uid: a37dc85c-bbfe-472a-acd2-1555fc6722de
spec:
  clusterName: aerosphere
  replicas: 3
  rollout:
    strategy:
      rollingUpdate:
        maxSurge: 1
        maxUnavailable: 0
      type: RollingUpdate
  selector:
    matchLabels:
      cluster.x-k8s.io/cluster-name: aerosphere
      topology.cluster.x-k8s.io/deployment-name: default
      topology.cluster.x-k8s.io/owned: ""
  template:
    metadata:
      annotations:
        cluster.x-k8s.io/cluster-api-autoscaler-node-group-max-size: "20"
        cluster.x-k8s.io/cluster-api-autoscaler-node-group-min-size: "3"
      labels:
        cluster.x-k8s.io/cluster-name: aerosphere
        topology.cluster.x-k8s.io/deployment-name: default
        topology.cluster.x-k8s.io/owned: ""
    spec:
      bootstrap:
        configRef:
          apiGroup: bootstrap.cluster.x-k8s.io
          kind: KubeadmConfigTemplate
          name: aerosphere-default-jg76p
      clusterName: aerosphere
      deletion:
        nodeDeletionTimeoutSeconds: 1800
        nodeDrainTimeoutSeconds: 1800
        nodeVolumeDetachTimeoutSeconds: 1800
      infrastructureRef:
        apiGroup: infrastructure.cluster.x-k8s.io
        kind: VSphereMachineTemplate
        name: aerosphere-default-j72pl
      version: v1.34.2
status:
  availableReplicas: 3
  conditions:
  - lastTransitionTime: "2026-05-25T13:19:28Z"
    message: ""
    observedGeneration: 17
    reason: Available
    status: "True"
    type: Available
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 17
    reason: NotRollingOut
    status: "False"
    type: RollingOut
  - lastTransitionTime: "2026-05-13T06:29:16Z"
    message: ""
    observedGeneration: 17
    reason: NotRemediating
    status: "False"
    type: Remediating
  - lastTransitionTime: "2026-05-26T07:09:22Z"
    message: ""
    observedGeneration: 17
    reason: NotScalingDown
    status: "False"
    type: ScalingDown
  - lastTransitionTime: "2026-05-24T22:17:55Z"
    message: ""
    observedGeneration: 17
    reason: NotScalingUp
    status: "False"
    type: ScalingUp
  - lastTransitionTime: "2026-05-26T07:09:22Z"
    message: ""
    observedGeneration: 17
    reason: Ready
    status: "True"
    type: MachinesReady
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 17
    reason: UpToDate
    status: "True"
    type: MachinesUpToDate
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 17
    reason: NotPaused
    status: "False"
    type: Paused
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 17
    reason: NotDeleting
    status: "False"
    type: Deleting
  deprecated:
    v1beta1:
      availableReplicas: 3
      conditions:
      - lastTransitionTime: "2026-05-27T06:12:18Z"
        status: "True"
        type: Ready
      - lastTransitionTime: "2026-05-27T06:12:18Z"
        status: "True"
        type: Available
      - lastTransitionTime: "2026-05-26T07:09:22Z"
        status: "True"
        type: MachineSetReady
      readyReplicas: 3
      unavailableReplicas: 0
      updatedReplicas: 3
  observedGeneration: 17
  phase: Running
  readyReplicas: 3
  replicas: 3
  selector: cluster.x-k8s.io/cluster-name=aerosphere,topology.cluster.x-k8s.io/deployment-name=default,topology.cluster.x-k8s.io/owned=
  upToDateReplicas: 3

apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
kind: VSphereMachineTemplate
metadata:
  annotations:
    cluster.x-k8s.io/cloned-from-groupkind: VSphereMachineTemplate.infrastructure.cluster.x-k8s.io
    cluster.x-k8s.io/cloned-from-name: vsphere-9.1.1865-worker-machinetemplate
    helm.sh/resource-policy: keep
    meta.helm.sh/release-name: vmsp-configs
    meta.helm.sh/release-namespace: vmsp-platform
  creationTimestamp: "2026-05-12T12:51:25Z"
  generation: 1
  labels:
    app.kubernetes.io/instance: vmsp-configs
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: vmsp-configs
    app.kubernetes.io/version: 9.1.1865
    cluster.x-k8s.io/cluster-name: aerosphere
    helm.sh/chart: vmsp-configs-9.1.1865
    helm.toolkit.fluxcd.io/name: vmsp-configs
    helm.toolkit.fluxcd.io/namespace: vmsp-platform
    topology.cluster.x-k8s.io/deployment-name: default
    topology.cluster.x-k8s.io/owned: ""
  name: aerosphere-default-j72pl
  namespace: vmsp-platform
  ownerReferences:
  - apiVersion: cluster.x-k8s.io/v1beta2
    kind: Cluster
    name: aerosphere
    uid: f2eca7f5-de56-4500-8a7c-bf295ef842d3
  resourceVersion: "23039"
  uid: 4bccfe6d-a9bb-46c2-aa73-a861cc6fd709
spec:
  template:
    spec:
      cloneMode: fullClone
      datacenter: Datacenter:datacenter-1001
      datastore: Datastore:datastore-672582
      diskGiB: 100
      folder: Folder:group-v683669
      memoryMiB: 24576
      namingStrategy:
        template: aerosphere-{{ trunc -5 .machine.name }}
      network:
        devices:
        - addressesFromPools:
          - apiGroup: ipam.cluster.x-k8s.io
            kind: InClusterIPPool
            name: aerosphere-global-ip-pool
          dhcp4: false
          dhcp6: false
          nameservers:
          - 192.168.1.5
          - 192.168.1.27
          networkName: DistributedVirtualPortgroup:dvportgroup-1069
      numCPUs: 12
      os: Linux
      powerOffMode: trySoft
      resourcePool: ResourcePool:resgroup-672691
      server: borealis.leaha.co.uk
      storagePolicyName: ""
      template: VirtualMachine:vm-683670

apiVersion: cluster.x-k8s.io/v1beta2
kind: Cluster
metadata:
  creationTimestamp: "2026-05-12T12:51:24Z"
  finalizers:
  - cluster.cluster.x-k8s.io
  generation: 110
  labels:
    app.kubernetes.io/instance: vmsp-cluster-aerosphere
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/name: vmsp-cluster
    app.kubernetes.io/version: 9.1.1865
    cluster.x-k8s.io/cluster-name: aerosphere
    controlplane.vmsp.vmware.com/cloud-provider: vsphere
    helm.sh/chart: vmsp-cluster-9.1.1865
    helm.toolkit.fluxcd.io/name: vmsp-cluster-aerosphere
    helm.toolkit.fluxcd.io/namespace: vmsp-platform
    topology.cluster.x-k8s.io/owned: ""
  name: aerosphere
  namespace: vmsp-platform
  resourceVersion: "14160176"
  uid: f2eca7f5-de56-4500-8a7c-bf295ef842d3
spec:
  clusterNetwork:
    pods:
      cidrBlocks:
      - 198.18.0.0/17
    services:
      cidrBlocks:
      - 198.18.128.0/17
  controlPlaneEndpoint:
    host: 192.168.1.130
    port: 6443
  controlPlaneRef:
    apiGroup: controlplane.cluster.x-k8s.io
    kind: KubeadmControlPlane
    name: aerosphere-25ndd
  infrastructureRef:
    apiGroup: infrastructure.cluster.x-k8s.io
    kind: VSphereCluster
    name: aerosphere-9dwkk
  topology:
    classRef:
      name: vsphere-9.1.1865
    controlPlane:
      replicas: 1
    variables:
    - name: network
      value: DistributedVirtualPortgroup:dvportgroup-1069
    - name: credsSecretName
      value: aerosphere-vsphere-secret
    - name: dhcp6Enabled
      value: false
    - name: infraServerThumbprint
      value: 1A:65:C2:2A:F1:64:75:0C:74:BF:00:6A:A4:F1:E3:40:16:7A:78:61
    - name: datacenter
      value: Datacenter:datacenter-1001
    - name: dhcp4Enabled
      value: false
    - name: datastore
      value: Datastore:datastore-672582
    - name: storagePolicy
      value: ""
    - name: nodePrefix
      value: aerosphere
    - name: ipPool
      value:
      - apiGroup: ipam.cluster.x-k8s.io
        kind: InClusterIPPool
        name: aerosphere-global-ip-pool
    - name: nameservers
      value:
      - 192.168.1.5
      - 192.168.1.27
    - name: ntpServers
      value:
      - time.cloudflare.com
    - name: infraServerURL
      value: borealis.leaha.co.uk
    - name: resourcePool
      value: ResourcePool:resgroup-672691
    - name: folder
      value: Folder:group-v683669
    - name: addressFamily
      value: ipv4
    - name: vmTemplate
      value: VirtualMachine:vm-683670
    - name: dnsImageTag
      value: v1.12.4
    - name: etcdImageTag
      value: 3.6.5-0
    - name: imageRepository
      value: registry.vmsp-platform.svc.cluster.local:5000/images
    - name: kubeVipPodManifest
      value: |
        apiVersion: v1
        kind: Pod
        metadata:
          creationTimestamp: null
          name: kube-vip
          namespace: kube-system
        spec:
          containers:
          - args:
            - manager
            env:
            - name: vip_arp
              value: "true"
            - name: port
              value: "6443"
            - name: vip_interface
              value: ""
            - name: vip_cidr
              value: "32"
            - name: cp_enable
              value: "true"
            - name: cp_namespace
              value: kube-system
            - name: vip_ddns
              value: "false"
            - name: svc_enable
              value: "false"
            - name: svc_leasename
              value: plndr-svcs-lock
            - name: svc_election
              value: "true"
            - name: vip_leaderelection
              value: "false"
            - name: vip_leasename
              value: plndr-cp-lock
            - name: vip_leaseduration
              value: "15"
            - name: vip_renewdeadline
              value: "10"
            - name: vip_retryperiod
              value: "2"
            - name: vip_preserve_on_leadership_loss
              value: "false"
            - name: address
              value: ${CONTROL_PLANE_ENDPOINT_IP}
            - name: prometheus_server
              value: :2112
            image: registry.vmsp-platform.svc.cluster.local:5000/images/kube-vip:v1.0.2
            imagePullPolicy: IfNotPresent
            name: kube-vip
            resources:
              requests:
                cpu: 50m
                memory: 100Mi
              limits:
                cpu: 200m
                memory: 256Mi
            securityContext:
              capabilities:
                add:
                - NET_ADMIN
                - NET_RAW
            volumeMounts:
            - mountPath: /etc/kubernetes/admin.conf
              name: kubeconfig
            - mountPath: /etc/hosts
              name: etchosts
          hostNetwork: true
          volumes:
          - hostPath:
              path: /etc/kubernetes/admin.conf
              type: FileOrCreate
            name: kubeconfig
          - hostPath:
              path: /etc/kube-vip.hosts
              type: File
            name: etchosts
        status: {}
    - name: kubeApiServer
      value:
        cpuRequest: 250m
        defaultWatchCacheSize: "150"
        gogc: "85"
        gomemlimit: 3200MiB
        memoryLimit: 3500Mi
        memoryRequest: 512Mi
        watchCacheSizes: secrets#300,pods#300,deployments#150,statefulsets#75,daemonsets#75,replicasets#75,configmaps#150,endpoints#150,services#150,events#0,customresourcedefinitions#150,apiservices#75,leases#300,helmreleases#300,machines#200,machinedeployments#150,clusters#150,updaterequests#300,selfsubjectaccessreviews#500
    - name: controlPlaneIpAddr
      value: 192.168.1.130
    - name: numCPUs
      value: 4
    - name: memoryMiB
      value: 10240
    - name: diskGiB
      value: 100
    - name: taintControlPlane
      value: true
    - name: user
      value:
        passwordSecret:
          key: sshPassword
          name: aerosphere-ssh-password-secret
    version: v1.34.2
    workers:
      machineDeployments:
      - class: vsphere-9.1.1865-worker
        metadata:
          annotations:
            cluster.x-k8s.io/cluster-api-autoscaler-node-group-max-size: "20"
            cluster.x-k8s.io/cluster-api-autoscaler-node-group-min-size: "3"
        name: default
        variables:
          overrides:
          - name: numCPUs
            value: 12
          - name: memoryMiB
            value: 24576
          - name: diskGiB
            value: 100
status:
  conditions:
  - lastTransitionTime: "2026-05-28T02:54:24Z"
    message: ""
    observedGeneration: 110
    reason: Available
    status: "True"
    type: Available
  - lastTransitionTime: "2026-05-14T15:20:51Z"
    message: ""
    observedGeneration: 110
    reason: ProbeSucceeded
    status: "True"
    type: RemoteConnectionProbe
  - lastTransitionTime: "2026-05-25T08:30:51Z"
    message: ""
    observedGeneration: 110
    reason: Ready
    status: "True"
    type: InfrastructureReady
  - lastTransitionTime: "2026-05-12T12:51:36Z"
    message: ""
    observedGeneration: 2
    reason: Initialized
    status: "True"
    type: ControlPlaneInitialized
  - lastTransitionTime: "2026-05-28T02:54:24Z"
    message: ""
    observedGeneration: 110
    reason: Available
    status: "True"
    type: ControlPlaneAvailable
  - lastTransitionTime: "2026-05-25T13:19:28Z"
    message: ""
    observedGeneration: 110
    reason: Available
    status: "True"
    type: WorkersAvailable
  - lastTransitionTime: "2026-05-27T06:12:19Z"
    message: ""
    observedGeneration: 110
    reason: ReconcileSucceeded
    status: "True"
    type: TopologyReconciled
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 110
    reason: NotRollingOut
    status: "False"
    type: RollingOut
  - lastTransitionTime: "2026-05-13T06:29:16Z"
    message: ""
    observedGeneration: 110
    reason: NotRemediating
    status: "False"
    type: Remediating
  - lastTransitionTime: "2026-05-26T07:09:22Z"
    message: ""
    observedGeneration: 110
    reason: NotScalingDown
    status: "False"
    type: ScalingDown
  - lastTransitionTime: "2026-05-24T22:17:55Z"
    message: ""
    observedGeneration: 110
    reason: NotScalingUp
    status: "False"
    type: ScalingUp
  - lastTransitionTime: "2026-05-28T02:54:24Z"
    message: ""
    observedGeneration: 110
    reason: Ready
    status: "True"
    type: ControlPlaneMachinesReady
  - lastTransitionTime: "2026-05-26T07:09:22Z"
    message: ""
    observedGeneration: 110
    reason: Ready
    status: "True"
    type: WorkerMachinesReady
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 110
    reason: UpToDate
    status: "True"
    type: ControlPlaneMachinesUpToDate
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 110
    reason: UpToDate
    status: "True"
    type: WorkerMachinesUpToDate
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 110
    reason: NotPaused
    status: "False"
    type: Paused
  - lastTransitionTime: "2026-05-12T12:51:31Z"
    message: ""
    observedGeneration: 110
    reason: NotDeleting
    status: "False"
    type: Deleting
  controlPlane:
    availableReplicas: 1
    desiredReplicas: 1
    readyReplicas: 1
    replicas: 1
    upToDateReplicas: 1
  deprecated:
    v1beta1:
      conditions:
      - lastTransitionTime: "2026-05-25T08:30:51Z"
        status: "True"
        type: Ready
      - lastTransitionTime: "2026-05-12T12:51:36Z"
        status: "True"
        type: ControlPlaneInitialized
      - lastTransitionTime: "2026-05-12T12:51:36Z"
        status: "True"
        type: ControlPlaneReady
      - lastTransitionTime: "2026-05-25T08:30:51Z"
        status: "True"
        type: InfrastructureReady
      - lastTransitionTime: "2026-05-27T06:12:19Z"
        status: "True"
        type: TopologyReconciled
  initialization:
    controlPlaneInitialized: true
    infrastructureProvisioned: true
  observedGeneration: 110
  phase: Provisioned
  workers:
    availableReplicas: 3
    desiredReplicas: 3
    readyReplicas: 3
    replicas: 3
    upToDateReplicas: 3

apiVersion: releases.vmsp.vmware.com/v1alpha1
kind: PackageDeployment
metadata:
  creationTimestamp: "2026-05-12T12:51:38Z"
  finalizers:
  - releases.vmsp.vmware.com/finalizer
  generation: 11
  labels:
    backup.vmsp.vmware.com/platform: "true"
    backup.vmsp.vmware.com/skip-restore: "true"
    component.vmsp.vmware.com/id: ae05f3e0-1b68-4a70-87c8-5a27bb70f9bc
    component.vmsp.vmware.com/name: vsp
    component.vmsp.vmware.com/type: vsp
    component.vmsp.vmware.com/version: 9.1.0.0.25370367
    packages.vcf.vmware.com/component: vsp
    packages.vcf.vmware.com/name: vmsp-platform
    packages.vcf.vmware.com/version: 9.1.0.0.25370367
  name: vmsp-platform
  namespace: vmsp-platform
  resourceVersion: "17906959"
  uid: ae3406ee-b815-4aa4-b89c-140aa56d7543
spec:
  packages:
  - name: envoyproxy-gateway
    version: v1.5.0-4
  - name: vmsp-global-config
    version: 9.1.1865
  - name: logging-operator
    version: 4.11.4-6
  - name: support-bundle
    version: 9.1.1865
  - name: reloader
    version: v1.4.12
  - name: cluster-api-installer
    version: v1.11.1
  - name: vsphere-cpi
    version: 1.34.0
  - name: gateway-api
    version: v1.3.0-7
  - name: antrea
    version: 2.4.2-1
  - name: coredns
    version: v1.12.4
  - name: vmsp-api
    version: 9.1.1865
  - name: trust-manager
    version: v0.20.3
  - name: vmsp-scripts
    version: v9.1.1865
  - name: seaweedfs
    version: 3.96.0-6
  - name: node-problem-detector
    version: v0.8.25
  - name: zalando-pg-operator
    version: v1.14.4-2
  - name: debug
    version: 1.0.8
  - name: etcd-defrag
    version: 0.37.0
  - name: flux2
    version: 2.17.1-1
  - name: cpa
    version: 1.9.1-1
  - name: argo-workflows
    version: 0.45.27-5
  - name: metrics-server
    version: 3.13.0-1
  - name: velero
    version: v1.16.2-9
  - name: vmsp-hooks
    version: 9.1.1865
  - name: kube-prometheus-stack
    version: 51.10.7-13
  - name: vmsp-backup
    version: 9.1.1865
  - name: namespace-config
    version: 0.1.10
  - name: kube-rbac-proxy
    version: v0.20.0
  - name: kyverno-policies
    version: 3.5.2-26
  - name: busybox
    version: 1.36.2-1
  - name: kyverno
    version: 1.15.2-4
  - name: ndc
    version: v9.1.1865
  - name: cluster-autoscaler
    version: 9.5.1-3
  - name: vsphere-csi
    version: 3.6.1-3
  - name: vmsp-configs
    version: 9.1.1865
  - name: kubernetes
    version: 1.0.8-2
  - name: vmsp-identity
    version: v9.1.1865
  - name: proxy-service
    version: 9.1.1865
  - name: metadata-service
    version: 9.1.1865
  - name: vmsp-etcd
    version: 3.6.5-4
  - name: vmsp-certs
    version: 9.1.1865
  - name: descheduler
    version: v0.33.0-4
  - name: vmsp-cluster
    version: 9.1.1865
  - name: zot
    version: v2.1.11-3
  - name: kube-vip
    version: v1.0.2-2
  - name: strimzi-kafka-operator
    version: v0.48.0-1
  - name: vmsp-agent
    version: v9.1.1865
  - name: synthetic-checker
    version: v9.1.1865
  - name: vmsp-operator
    version: v9.1.1865
  - name: cert-manager
    version: v1.18.2-5
  - name: argo-templates
    version: v9.1.1865
  - name: gatewayconfiguration
    version: 9.1.1865
  suspend: {}
  templateSelector: {}
  values:
    backups:
      destination: sftp
      full:
        enable: true
        schedule: 10 0 * * MON,TUE,WED,THU,FRI,SAT,SUN
      incremental:
        enable: false
        schedule: '*/15 * * * *'
      retention:
        maxAgeDays: 7
        maxBackups: -1
      storage:
        sftp:
          fingerprint: SHA256:LjIZbgd6sU5G1d4jIvimEJdRJpF4wrkT0xOGm8IJRDU
    ceip: {}
    cluster:
      generation: 0
      ha: "false"
      id: ae05f3e0-1b68-4a70-87c8-5a27bb70f9bc
      name: aerosphere
      nodePrefix: aerosphere
      type: management
      vmspVMMode: bootstrap
      worker:
        enabled: true
        machineType: management.large
        minReplicas: 3
        size: large
    depot:
      url: https://skyveil.leaha.co.uk/depot-service/content-gateway
    flags:
      assignNodesToVMGroup: true
      pdbs: "true"
    helmRepository:
      certSecretRef: registry-certificate
      insecure: false
    ingress:
      fleet:
        fqdn: skyveil.leaha.co.uk
        vips:
          ipv4:
          - 192.168.1.91
          ipv6: []
      instance:
        fqdn: windspire.leaha.co.uk
        vips:
          ipv4:
          - 192.168.1.92
          ipv6: []
      platform:
        fqdn: aerosphere.leaha.co.uk
        vips:
          ipv4:
          - 192.168.1.90
          ipv6: []
    logs:
      loginsight:
        host: mistral.leaha.co.uk
        port: 9543
        scheme: https
        sslVerify: false
      syslog:
        host: ""
        insecure: true
        transport: tcp
      type: loginsight
    network:
      addressFamily: ipv4
      dhcp: false
      dhcp6: false
      dnsServers:
      - 192.168.1.5
      - 192.168.1.27
      gateway:
        type: envoy
      ingress:
        vips:
          controlplane: 192.168.1.130
          primary: ""
      internal:
        cidr: 198.18.0.0/15
        cidrv6: ""
        clusterCIDR: 198.18.0.0/16
        clusterCIDRv6: ""
        serviceCIDR: 198.18.128.0/17
        serviceCIDRv6: ""
      ipPool:
        addresses:
        - 192.168.1.128/28
        excludedAddresses:
        - 192.168.1.90
        - 192.168.1.91
        - 192.168.1.92
        - 192.168.1.130
        gateway: 192.168.1.1
        prefix: "24"
      ipPoolv6:
        addresses: []
        excludedAddresses: []
        gateway: ""
        prefix: ""
      ntpServers:
      - time.cloudflare.com
    objectStorage:
      filerBacking: etcd
    profiles:
      name: small
    provider:
      vsphere:
        cluster: /Homelab/host/Cryosphere
        clusterId: ClusterComputeResource:domain-c671572
        datacenter: /Homelab
        datacenterId: Datacenter:datacenter-1001
        datastore: /Homelab/datastore/Triton
        datastoreId: Datastore:datastore-672582
        datastoreURL: ds:///vmfs/volumes/vsan:119e14b026f911f1-9185005056b9f29b/
        enriched: "true"
        folder: /Homelab/vm/vcf-management-services
        folderId: Folder:group-v683669
        host: borealis.leaha.co.uk
        insecureTLS: false
        network: /Homelab/network/vSphere-MGMT-1
        networkId: DistributedVirtualPortgroup:dvportgroup-1069
        port: "443"
        resourcePool: /Homelab/host/Cryosphere/Resources/VCF Appliances
        resourcePoolId: ResourcePool:resgroup-672691
        server: borealis.leaha.co.uk
        templateFolder: /Homelab/vm/vcf-management-services
        templateFolderId: Folder:group-v683669
        templateId: VirtualMachine:vm-683670
        thumbprint: 1A:65:C2:2A:F1:64:75:0C:74:BF:00:6A:A4:F1:E3:40:16:7A:78:61
        tlsCertificate: 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
        vmGroup: Cryosphere_primary-az-vmgroup
    registry:
      server: registry.vmsp-platform.svc.cluster.local:5000
      service:
        enabled: true
        nodePort: 30000
        port: 5000
        type: ClusterIP
      storageType: pvc
    security:
      enforcePasswordPolicy: "true"
      passwordPolicy:
        complexityConstraint:
          minLength: 15
          minLowercase: 1
          minNumeric: 1
          minSpecial: 1
          minUppercase: 1
          passwordHistory: 5
        expirationConstraint:
          passwordExpirationDays: 365
        lockoutConstraint:
          lockoutEvaluationPeriod: 900
          lockoutMaxAuthFailures: 3
          lockoutPeriod: 900
        policyId: default
        policyInfo:
          description: VSP Default Password Policy
          policyName: VSP Default Password Policy
    sftp:
      directory: /mnt/Sol/General/Backups/VCF/
      host: 192.168.1.4
      port: "22"
      username: leaha
    ssh:
      publicKey: ""
    vcf:
      opsMgmt:
        host: ""
        username: ""
    zot:
      config:
        auth:
          enable: false
status:
  builtInsDigest: 84e657f5f4e5a4d87a2b37464b2f7347b12d376d21f31877aba3202e88f50fb1
  conditions:
  - lastTransitionTime: "2026-05-12T12:51:38Z"
    message: found templates for provided package
    observedGeneration: 1
    reason: MatchedTemplates
    status: "True"
    type: TemplatesIdentified
  - lastTransitionTime: "2026-05-31T20:31:46Z"
    message: 'failed to create or patch helmrelease vmsp-platform.node-problem-detector:
      Internal error occurred: failed calling webhook "validate.kyverno.svc-fail":
      failed to call webhook: Post "https://kyverno-svc.vmsp-policies.svc:443/validate/fail?timeout=10s":
      dial tcp 198.18.219.19:443: connect: connection refused'
    observedGeneration: 11
    reason: DeploymentFailed
    status: "False"
    type: Ready
  observedGeneration: 11
  packageDeployments:
  - name: antrea
    releases:
    - name: antrea
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: argo-templates
    releases:
    - message: 'Could not determine release state: failed to retrieve last release
        from storage: query: failed to query with labels: Get "https://192.168.1.130:6443/api/v1/namespaces/vmsp-platform/secrets?labelSelector=name%3Dargo-templates%2Cowner%3Dhelm":
        context deadline exceeded (Client.Timeout exceeded while awaiting headers)'
      name: argo-templates
      namespace: vmsp-platform
      ready: "False"
      reason: StateError
  - name: argo-workflows
    releases:
    - name: argo-workflows
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: cert-manager
    releases:
    - name: cert-manager
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: cluster-api-installer
    releases:
    - name: cluster-api-installer
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: cluster-autoscaler
    releases:
    - name: cluster-autoscaler
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: descheduler
    releases:
    - name: descheduler
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: envoyproxy-gateway
    releases:
    - name: envoyproxy-gateway
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: flux2
    releases:
    - name: fluxcd
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: gateway-api
    releases:
    - name: gateway-api
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: gatewayconfiguration
    releases:
    - name: gatewayconfiguration
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: kube-prometheus-stack
    releases:
    - name: kube-prometheus-stack
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: kube-vip
    releases:
    - name: kube-vip
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: kyverno
    releases:
    - name: kyverno
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: kyverno-policies
    releases:
    - name: kyverno-policies
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
    - message: 'Could not determine release state: failed to retrieve last release
        from storage: query: failed to query with labels: Get "https://192.168.1.130:6443/api/v1/namespaces/vmsp-platform/secrets?labelSelector=name%3Dvmsp-kyverno-policies%2Cowner%3Dhelm":
        context deadline exceeded (Client.Timeout exceeded while awaiting headers)'
      name: vmsp-kyverno-policies
      namespace: vmsp-platform
      ready: "False"
      reason: StateError
  - name: logging-operator
    releases:
    - name: logging-operator
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: metadata-service
    releases:
    - name: metadata-service
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: metrics-server
    releases:
    - message: 'Could not determine release state: failed to retrieve last release
        from storage: query: failed to query with labels: Get "https://192.168.1.130:6443/api/v1/namespaces/vmsp-platform/secrets?labelSelector=name%3Dmetrics-server%2Cowner%3Dhelm":
        context deadline exceeded (Client.Timeout exceeded while awaiting headers)'
      name: metrics-server
      namespace: vmsp-platform
      ready: "False"
      reason: StateError
  - name: ndc
    releases:
    - name: ndc
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: node-problem-detector
    releases:
    - name: node-problem-detector
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: proxy-service
    releases:
    - name: proxy-service
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: reloader
    releases:
    - name: reloader
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: seaweedfs
    releases:
    - name: seaweedfs
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: strimzi-kafka-operator
    releases:
    - name: strimzi-kafka-operator
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: support-bundle
    releases:
    - name: support-bundle
      namespace: vmsp-platform
      ready: "True"
      reason: InstallSucceeded
  - name: synthetic-checker
    releases:
    - name: hooks-server
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
    - name: synthetic-checker
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: trust-manager
    releases:
    - name: trust-manager
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: velero
    releases:
    - name: velero
      namespace: vmsp-platform
      ready: Unknown
      reason: DependencyNotReady
  - name: vmsp-agent
    releases:
    - message: 'Could not determine release state: failed to retrieve last release
        from storage: query: failed to query with labels: Get "https://192.168.1.130:6443/api/v1/namespaces/vmsp-platform/secrets?labelSelector=name%3Dvmsp-agent%2Cowner%3Dhelm":
        context deadline exceeded - error from a previous attempt: http2: client connection
        lost'
      name: vmsp-agent
      namespace: vmsp-platform
      ready: "False"
      reason: StateError
  - name: vmsp-api
    releases:
    - name: vmsp-api
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-backup
    releases:
    - name: vmsp-backup
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-certs
    releases:
    - name: vmsp-certs
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-cluster
    releases:
    - name: vmsp-cluster-aerosphere
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-configs
    releases:
    - name: vmsp-configs
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-etcd
    releases:
    - name: vmsp-etcd
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-global-config
    releases:
    - name: vmsp-global-config
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-hooks
    releases:
    - name: vmsp-hooks
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-identity
    releases:
    - message: 'Could not determine release state: unable to determine cluster state:
        [failed to determine if ServiceAccount is namespace scoped: failed to get
        restmapping: failed to get server groups: unexpected error when reading response
        body. Please retry. Original error: context deadline exceeded (Client.Timeout
        or context cancellation while reading body), failed to determine if ClusterRole
        is namespace scoped: failed to get restmapping: failed to get server groups:
        Get "https://192.168.1.130:6443/api?timeout=30s": context deadline exceeded
        - error from a previous attempt: http2: client connection lost, failed to
        determine if ClusterRole is namespace scoped: failed to get restmapping: failed
        to get server groups: Get "https://192.168.1.130:6443/api?timeout=30s": context
        deadline exceeded, Get "https://192.168.1.130:6443/apis/policy/v1/namespaces/vmsp-platform/poddisruptionbudgets/vmsp-identity?timeout=30s":
        context deadline exceeded, an empty namespace may not be set when a resource
        name is provided, Get "https://192.168.1.130:6443/apis/rbac.authorization.k8s.io/v1/clusterroles/vmsp-identity-manager-role?timeout=30s":
        context deadline exceeded - error from a previous attempt: http2: client connection
        lost, Get "https://192.168.1.130:6443/apis/rbac.authorization.k8s.io/v1/clusterroles/vmsp-identity-metrics-reader?timeout=30s":
        net/http: request canceled (Client.Timeout exceeded while awaiting headers),
        client rate limiter Wait returned an error: context deadline exceeded - error
        from a previous attempt: http2: client connection lost, Get "https://192.168.1.130:6443/apis/rbac.authorization.k8s.io/v1/clusterrolebindings/vmsp-identity-manager-rolebinding?timeout=30s":
        context deadline exceeded (Client.Timeout exceeded while awaiting headers),
        Get "https://192.168.1.130:6443/apis/rbac.authorization.k8s.io/v1/clusterrolebindings/vmsp-identity-proxy-rolebinding?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host, Get "https://192.168.1.130:6443/apis/rbac.authorization.k8s.io/v1/namespaces/vmsp-platform/roles/vmsp-identity-leader-election-role?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host, Get "https://192.168.1.130:6443/apis/rbac.authorization.k8s.io/v1/namespaces/vmsp-platform/rolebindings/vmsp-identity-leader-election-rolebinding?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host, Get "https://192.168.1.130:6443/api/v1/namespaces/vmsp-platform/services/vmsp-identity-auth-service?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host, Get "https://192.168.1.130:6443/api/v1/namespaces/vmsp-platform/services/vmsp-identity-webhook-service?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host, Get "https://192.168.1.130:6443/apis/apps/v1/namespaces/vmsp-platform/deployments/vmsp-identity?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host, Get "https://192.168.1.130:6443/apis/identity.vmsp.vmware.com/v1alpha1/namespaces/vmsp-platform/accessgrants/fleetbuilder-grants?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host, Get "https://192.168.1.130:6443/apis/identity.vmsp.vmware.com/v1alpha1/namespaces/vmsp-platform/accessgrants/ops-logs-grants?timeout=30s":
        dial tcp 192.168.1.130:6443: connect: no route to host]'
      name: vmsp-identity
      namespace: vmsp-platform
      ready: "False"
      reason: StateError
  - name: vmsp-operator
    releases:
    - name: vmsp-operator
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vmsp-scripts
    releases:
    - name: vmsp-scripts
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vsphere-cpi
    releases:
    - name: vsphere-cpi
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: vsphere-csi
    releases:
    - name: vsphere-csi
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: zalando-pg-operator
    releases:
    - name: zalando-postgres-operator
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  - name: zot
    releases:
    - name: zot-2
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
    - name: zot-1
      namespace: vmsp-platform
      ready: "True"
      reason: UpgradeSucceeded
  phase: Failed
